Input types
•
Digital or Analog (DIN/AIN)
•
Analog Input Offset
•
A/D Refresh Rate
•
Digital/Analog/Frequency (DIN/AIN/FreqIN)
•
Digital/Analog/Resistance/4-20 mA Current (DIN/AIN/ResIN/CrntIN)
•
Digital/Analog/1.6 Vdc Sensor Power (DIN/AIN/SnsrPwr1.6Vdc)
•
Digital/Analog/3.6 Vdc Sensor Power (DIN/AIN/SnsrPwr3.6Vdc)
Each PLUS+1
®
module input pin supports one of the above functional types. For pins with multiple
functions, input configurations are user programmable using PLUS+1
®
GUIDE templates.
Digital/Analog (DIN/AIN), A/D Refresh Rates
Multifunction pins that are configured to be DIN are subject to the same update rates as the analog input
function for that pin. Debounce is not used, as hysteresis is built into the function. The time to recognize
a transition is dependent on the timing of the switch activation and the sample rate.
General
Description Comment
Response to input below minimum voltage Non-damaging, non-latching; reading saturates to the low limit.
Response to input above maximum voltage Non-damaging, non-latching; reading saturates to the high limit.
Response to input open Pin configuration dependent: No pull up/ no pull down = floating
Pull up to 5 Vdc = 5 Vdc
Pull down = 0 Vdc
Pull up/ pull down = 2.5 Vdc
Voltage working ranges Programmable (see specific data sheets for ranges).
Specifications
Description Units Minimum Maximum Comment
Allowed voltage at pin Vdc 0 36 — —
Maximum discernable voltage (high range) Vdc 34.10 36.5 35.3 Vdc is typical.
Minimum discernable voltage (high range) mV 0 130 — —
Maximum discernable voltage (middle range Vdc 5.13 5.38 5.26 Vdc is typical.
Minimum discernable voltage (low range) mV 0 20 — —
Precision (high range) mV — — 9 — —
Worst case error (high range) Vdc — — 1.16 — —
Precision (middle range) mV — — 1.3 — —
Worst case error (middle range) mV — — 120 — —
Input impedance (pulled up to 5 Vdc or ground, middle range) kΩ 13.9 14.3 — —
Input impedance (pulled up to 2.5 Vdc middle range) kΩ 7.2 7.4 — —
Input impedance (no pull ups, middle range) kΩ 230 236 — —
Input impedance (pulled up to 5 Vdc or ground, high range) kΩ 13.0 13.4 — —
Input impedance (pulled up to 2.5 Vdc high range) kΩ 6.9 7.1 — —
Input impedance (no pull ups, high range) kΩ 108 112 — —
Technical Information
PLUS+1 SC0XX-1XX Controller Family
Inputs
8 |
©
Danfoss | June 2016 L1415500 | BC00000235en-US0201
