Three operating data items can be shown in the first
display line, and one operating variable can be shown
in the second display line. Is programmed via param-
eters 009, 010, 011 and 012 Display readout .
Display modes
The LCP control unit has different display modes,
which depend on the mode selected for the frequency
converter.
Display mode I:
This display mode is standard after startup or initiali-
sation.
50.0 Hz
FREQUENCY
MOTOR IS RUNNING
Line 2 shows the data value of an operating data item
with unit, and line 1 contains a text that explains line 2.
In the example, Frequency has been selected as read-
out via parameter 009 Large display readout. In normal
operation, another variable can be entered immedi-
ately using the [+ / -] keys.
Display mode II:
Switch between Display modes I and II is performed
by briefly pressing the [DISPLAY / STATUS] key.
MOTOR IS RUNNING
50.0 Hz
24.3% 30.2% 13.8A
In this mode, all data values for four operating data
items with any pertaining units are shown, see table.
In the example, the following have been selected: Fre-
quency, Reference, Torque and Current as readout in
the first and second line.
Display mode III:
This display mode is called up as long as the [DIS-
PLAY / STATUS] key is held down. When the key is
released it switches back to Display mode II, unless
the key is held down for less than approx. 1 sec., in
which case the system always reverts to Display mode
I.
50.0 Hz
SETUP
1
MOTOR IS RUNNING
REF% TORQUE CURR A
Here you can read out the parameter names and units
for operating data in the first and second lines. Line 2
in the display remains unchanged.
Display mode IV:
This display mode can be called up during operation if
a change has to be made in another Setup without
stopping the frequency converter. This function is ac-
tivated in parameter 005 Programming Setup.
50.0 Hz
SETUP
1
MOTOR IS RUNNING
REF% TORQUE CURR A
Here the programming Setup number 2 will flash to the
right of the active Setup.
Parameter Setup
A frequency converter's comprehensive work area can
be accessed via a large number of parameters, mak-
ing it possible to adapt its functionality for a specific
application. To provide a better overview of the many
parameters, there is a choice of two programming
modes - Menu mode and Quick Menu mode. The for-
mer provides access to all parameters. The latter takes
the user through the parameters, which make it pos-
sible to start operating the frequency converter in most
cases, in accordance with the Setup made. Regard-
less of the mode of programming, a change of a pa-
rameter will take effect and be visible both in the Menu
mode and in the Quick menu mode.
Structure for Quick menu mode v Menu mode
In addition to having a name, each parameter is linked
up with a number which is the same regardless of the
programming mode. In Menu mode, parameters will
be split into groups, with the first digit (left) of the pa-
rameter number indicating the group number of the
parameter in question.
34 MG.27.E2.02 - VLT is a registered Danfoss trademark
