Motor voltage [V]
(Motor voltage [V]) [11]
DC link voltage [V]
(DC link voltage [V]) [12]
Thermal load motor [%]
(Motor thermal [%]) [13]
Thermal load [%]
(FC. thermal[%]) [14]
Running hours [Hours]
(RUNNING HOURS]) [15]
Digital input [Bin]
(Digital input[bin]) [16]
Analog input 53 [V]
(analog input 53 [V]) [17]
Analog input 60 [mA]
(analog input 60 [mA]) [19]
Pulse reference [Hz]
(Pulse ref. [Hz]) [20]
External reference [%]
(external ref. [%]) [21]
Status word [Hex] (Status word [hex]) [22]
Heatsink temperature [°C]
(Heatsink temp [°C]) [25]
Alarm word [Hex] (Alarm word [hex]) [26]
Control word [Hex] (Control word [Hex]) [27]
Warning word [Hex]
(warning word [Hex]) [28]
Extended status word [Hex]
(Ext. status [hex]) [29]
Communication option card warning
(COMM OPT WARN [HEX]) [30]
Pulse count
(PULSE COUNTER) [31]
Power [W]
(POWER [W]) [32]
Function:
In this parameter you can select the data value that
you wish to display in the LCP 2 control unit display
line 2 when the frequency converter is switched on.
The display will also be included in the scrollbar in dis-
play mode. In parameters 010-012 Display readout you
can select a further three data values, which are dis-
played in display line 1.
Description of choice:
No readout can only be selected in parameters
010-012 Small display readout.
Resulting reference [%] gives, as a percentage, the re-
sulting reference in the range from Minimum refer-
ence, Ref
MIN
to Maximum reference, Ref
MAX
.
Reference [unit] gives the resulting reference with unit
Hz in Open loop. In Closed loop the reference unit is
selected in parameter 416 Process units.
Feedback [unit] gives the resulting signal value using
the unit/scaling selected in parameter 414 Minimum
feedback, FB
LOW
, 415 Maximum feedback, FB
HIGH
and
416 Process units.
Frequency [Hz] gives the output frequency of the fre-
quency converter.
Output frequency x scaling [-] equals the present output
frequency f
M
multiplied by the factor set in parameter
008 Display scaling of output frequency .
Motor current [A] gives the phase current of the motor
measured as an effective value.
Torque [%] denotes the motor's present load in relation
to the motor's rated torque.
Power [kW] gives the present power that the motor is
absorbing in kW.
Power [HP] gives the present power that the motor is
absorbing in HP.
Motor voltage[V] gives the voltage supplied to the mo-
tor.
DC link voltage [V] gives the intermediate circuit voltage
of the frequency converter.
Thermal load motor [%] gives the calculated/estimated
load on the motor. 100 % is the cut-out limit.
Thermal load [%] gives the calculated/estimated ther-
mal load on the frequency converter. 100 % is the cut-
out limit.
Running hours [Hours] gives the number of hours that
the motor has tun since the last reset in parameter 619
Reset of running hours counter.
Digital input [Binary code] gives the signal status from
the 5 digital inputs (18, 19, 27, 29 and 33). Terminal
18 corresponds to the bit on the extreme left. `0' = no
signal, `1' = signal connected.
Analog input 53 [V] gives the voltage value of terminal
53.
Analog input 60 [mA] gives the present value of termi-
nal 60.
Pulse reference [Hz] gives the reference in Hz connec-
ted to terminal 33.
= factory setting, () = display text, [] = value for use in communication via serial communication port
62 MG.27.E2.02 - VLT is a registered Danfoss trademark
