VLT
®
Series 3500
81
★ = ROM default setting. ✔ = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.
407 Terminal 42 Output (OUTPUT 42)
Value:
Control ready (CONTROL READY) [0]
Unit ready (UNIT READY) [1]
Ready - remote control (UNT RDY RCTL) [2]
Enabled (ENABLED noWR) [3]
Running (RUNNING) [4]
Running, no warning (RUNNING noWR) [5]
Running in range, no warning (RUNinRANGE) [6]
Speed = reference, no warning
(RUN@REF noWR) [7]
Alarm (ALARM) [8]
Alarm or warning (ALARM or WARN) [9]
Current limit (CURRENT LIMIT) [10]
Out of frequency range (OUT FREQ RGE) [11]
Warning of low freq.(LO FREQ. WARN) [12]
Warning of high freq.(HI FREQ. WARN) [13]
Out of current range (OUT CURR RGE) [14]
Warning of low current (LO CURR. WARN) [15]
Warning of high current (HI CURR. WARN) [16]
0 to 100 Hz 0 to 20 mA(100 Hz 0 to 20 mA) [17]
0 to 100 Hz 4 to 20 mA(100 Hz 4 to 20 mA) [18]
0 to f
MAX
0 to 20 mA(Fmax 0 to 20 mA) [19]
0 to f
MAX
4 to 20 mA (Fmax 4 to 20 mA) [20]
REF
MIN
to REF
MAX
0 to 20 mA(REFmax 0 to 20 mA) [21]
REF
MIN
to REF
MAX
4 to 20 mA(REFmax 4 to 20 mA) [22]
FB
MIN
to FB
MAX
0 to 20 mA(FBmax 0 to 20 mA) [23]
FB
MIN
to FB
MAX
4 to 20 mA(FBmax 4 to 20 mA) [24]
★ 0 to I
MAX
0 to 20 mA(CURmax 0 to 20 mA) [25]
✔ 0 to I
MAX
4 to 20 mA(CURmax 4 to 20 mA) [26]
0 to I
LIM
0 to 20 mA(CURlim 0 to 20 mA) [27]
0 to I
LIM
4 to 20 mA(CURlim 4 to 20 mA) [28]
0 to kW
MAX
0 to 20 mA(PWRlim 0 to 20 mA) [29]
0 to kW
MAX
4 to20 mA(PWRlim 4 to 20 mA) [30]
Function:
Terminals 42 and 45 can be programmed to give one of
these output signals: 24 V DC, (max. 40 mA); 0 to 20 mA;
or 4 to 20 mA.
The 24 V signal is used to report the status of a selected
drive status. The 0 to 20 mA and 4 to 20 mA outputs are
used for analog readouts.
Description of choice:
[0] VLT is ready for use.
[1] VLT is ready for use.
[2] VLT is in the remote mode and is ready for use.
[3] VLT is ready, there are no warnings.
[4] VLT is running (output frequency is > 0.5 Hz or has
a start signal).
[5] VLT is running (output frequency is > 0.5 Hz or has
a start signal), there are no warnings.
[6] VLT is running within the programmed frequency
and/or current range, there are no warnings.
[7] VLT output frequency corresponds to the reference,
there are no warnings.
[8] There is an alarm.
[9] There is a warning.
[10] The current limit set in parameter 209 has been ex-
ceeded.
[11] The motor is running out of the frequency range pro-
grammed in parameters 210 and 211.
[12] The motor is running below the frequency pro-
grammed in parameter 210.
[13] The motor is running above the frequency pro-
grammed in parameter 211.
[14] The motor is running out of the current range pro-
grammed in parameters 212 and 213.
[15] The motor current is below the current programmed
in parameter 212.
[16] The motor current is above the current programmed
in parameter 213.
[17- 18] The output signal represents the drive’s speed, 20
mA represents an output frequency of 100 Hz. The
minimum signal represents 0 Hz.
[19-20]The output signal represents the drive’s speed. 20
mA represents the frequency set in parameter 202.
The minimum signal represents 0 Hz.
[21-22]The output signal represents the total speed refer-
ence signal supplied to the drive from the three ex-
ternal inputs (set by parameters 401, 412, and 413)
and the bus reference (set by parameter 516). 20
mA represents the maximum speed reference sig-
nal and the minimum signal represents the mini-
mum speed reference signal. The drive does not
have to be running to display this reference signal.
[23-24] The output signal represents the feedback signal ap-
plied to terminal 17, 53 or 60, as setup by param-
eters 401, 412 or 413.
[25-26]The output signal represents the output current from
the drive. The maximum signal represents 110% of
the drive’s rated output current. The minimum sig-
nal represents no output current.
[27-28]The output signal represents the output current from
the drive. The maximum signal represents the cur-
rent limit value, set in parameter 208.
[29-30]The output signal represents the output power from
the drive. The maximum signal represents the
motor’s rated power, which was entered in param-
eter 103.
