VLT
®
Series 3500
95
= ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.
503 Coasting (COAST)
Value:
Digital (DIGITAL) [0]
Bus (BUS) [1]
Logical and (AND) [2]
Logical or (OR) [3]
504 Quick-Stop (Q-STOP)
Value:
Digital (DIGITAL) [0]
Bus (BUS) [1]
Logical and (AND) [2]
Logical or (OR) [3]
505 DC Brake (DC-BRAKE)
Value:
Digital (DIGITAL) [0]
Bus (BUS) [1]
Logical and (AND) [2]
Logical or (OR) [3]
506 Start (START)
Value:
Digital (DIGITAL) [0]
Bus (BUS) [1]
Logical and (AND) [2]
Logical or (OR) [3]
507 Direction of Rotation (DIRECTION)
Value:
Digital (DIGITAL) [0]
Bus (BUS) [1]
Logical and (AND) [2]
Logical or (OR) [3]
508 Reset (RESET)
Value:
Digital (DIGITAL) [0]
Bus (BUS) [1]
Logical and (AND) [2]
Logical or (OR) [3]
509 Selection of Setup (SETUP SELE)
Value:
Digital (DIGITAL) [0]
Bus (BUS) [1]
Logical and (AND) [2]
Logical or (OR) [3]
510 Selection of Speed (SPEED SELECT)
Value:
Digital (DIGITAL) [0]
Bus (BUS) [1]
Logical and (AND) [2]
Logical or (OR) [3]
Function (parameters 503 through 510):
These parameters are used for determining how control
commands from serial bus communication are to be priori-
tized in relation to the same control commands from the
digital inputs.
Description of choice (parameters 503 through 510):
Digital
is selected if the control command is only to be acti-
vated via a digital input.
Bus
is selected if the control command is only to be acti-
vated by means of serial bus communication.
Logical and
is selected if the control command is only to be
activated when the signal is active from both the serial bus
and the digital input. Active signal “1”.
Logical or
is selected if the control command in question is
to be activated when the signal is active from either the
control word or the digital input. Active signal “1”.
NOTE:
Parameters 503 through 505 concern stop func-
tions - see example concerning parameter 503,
coasting, on next page. Active stop signal is “0”.
