Appendix
BACnet POINT MAPPING TABLES
for BACLink PORTAL
Binary Inputs to Drive
The values in bold are default values.
NOTE
Binary input point 9 commands two different
functions. For VLT 2800, it commands
reverse function to change direction of
motor rotation. For VLT 6000, it can
command the state of Form C relay.
BACnet
REFERENCE NUMBER DESCRIPTION RANGE
coast_# Motor will coast freely to a stop.
Drive will not run in any mode
when coast is active.
0=Coast stop
1=No
coast
start_# Provides a start command when
active. Motor will ramp to stop
when stop is active.
0=Stop
1=Start
reset_# Allows resetting drive after a fault
that does not require cycling
power. Reset occurs at transition
from OFF to ON.
0=Off
1=On
jog_# Used to start and run drive at a
frequency set in parameter 209.
0=Off
1=On
vlt2800_relay_# Enables/disables high voltage
Form C relay when parameter 323
is set to
Control Word Bit 11
[26]
(for VLT 2800 only).
0=Off
1=On
vlt6000_relay_2_# Enables/disables low voltage
Form A relay when parameter 323
is set to
Control Word Bit 11/12
[29] (for VLT 6000 only).
0=Off
1=On
vlt6000_reverse_# Changes motor direction of
rotation when parameter 506 is set
to a value other than
Digital Input
(for VLT 6000 only).
0=Off
1=On
relay_1_and_reverse_# For VLT 2800, changes motor
direction of rotation.
For VLT 6000, enables/disables
high voltage Form C relay when
parameter 323 is set to
Control
Word Bit 11/12
[29].
0=Off
1=On
