Appendix
The values in bold are default values.
Drive Settings
BACnet
REFERENCE NAME DESCRIPTION RANGE
VLT 6000
PARA NO.
VLT 2800
PARA NO.
vlt6000_reset_counter_# Resets kWh counter
(for VLT 6000 only)
0=no rest
1=reset
618 VLT 6000
only
vlt6000_active_setup_# Selects active setup
(for VLT 6000 only)
1 to 4 002 VLT 6000
only
vlt2800_prop_gain_# PID proportional gain
(for VLT 2800 only)
0.00 to10.00 VLT 2800
only
440
vlt2800_int_time_# PID integration time
(for VLT 2800 only)
0.01 to
9999.00 sec.
VLT 2800
only
441
vlt2800_fb_filter_time_# Feedback filter time
(for VLT 2800 only)
0.01 to10.00
sec.
VLT 2800
only
444
warn_feedback_low_# Warning low feedback
(for VLT 6000 only)
-999,999.999
to FB high
227 VLT 6000
only
warn_feedback_high_# Warning high feedback
(for VLT 6000 only)
FB low to
999,999.999
228 VLT 6000
only
setpoint_1_# Set point 1
(for VLT 6000 only)
Min. FB to
max. FB
418 VLT 6000
only
setpoint_2_# Set point 2
(for VLT 6000 only)
Min. FB to
max. FB
419 VLT 6000
only
vlt6000_prop_gain_#
PID proportional gain
(for VLT 6000 only)
0.00 to10.00 423 VLT 6000
only
vlt6000_int_time_# PID integration time
(for VLT 6000 only)
0.01 to
9999.00 sec.
424 VLT 6000
only
vlt6000_fb_filter_time_# Feedback filter time
(for VLT 6000 only)
0.01 to10.00
sec.
427 VLT 6000
only
Analog Inputs to Drive
BACnet
REFERENCE NAME DESCRIPTION RANGE
VLT 6000
PARA No.
VLT 2800
PARA No.
bus_ref_# Drive speed command
(open loop) or setpoint
(closed loop) via the
serial bus.
0% to 100% N/A N/A
bus_feedback_# Drive feedback value
via the serial bus.
0% to 100% 535 535
bus_feedback_2_# Second drive feedback
value via the serial bus
available in the
VLT 6000 only.
0% to 100% 536 VLT 6000
only
Bus reference. When the drive is set for open loop operation in
parameter 100, the bus reference is the speed command to the
drive. In closed loop operation, bus reference is the drives
setpoint.
Bus feedback. This is the feedback signal provided to the drive
via the BACnet bus. The VLT 6000 can regulate two feedback
signals provided to the drive.
Range. Percentage of range between minimum reference
(parameter 204) and maximum reference (parameter 205).
NOTE: # symbol represents drive ID number.
NOTE: # symbol represents drive ID number.
