Danfoss VLT 6000 Instruction Manual

20
VLT is a registered Danfoss trademark
Appendix
NOTE: # symbol represents drive ID number.
Analog Outputs from Drive
BACNet
Reference Name UNIT DESCRIPTION
VLT 6000
PARA NO.
VLT 2800
PARA NO.
reference_# % Reference in % between min
and max reference. Speed
reference in open loop. Setpoint
reference in closed loop.
509 515
feedback_# Par.
415
Feedback using the unit of
measure selected in parameter
415.
511 517
freq_# Hz Drive output frequency. 512 518
motor_curr_# Amp Current being supplied to motor. 514 520
power_# kW Power being supplied to motor. 515 522
motor_volt_# VAC Voltage being supplied to motor. 517 524
dc_bus_volt_# VDC DC bus voltage of drive. 518 525
therm_motor_load_# % Calculated thermal load on
motor. Trip point is 100%.
519 526
therm_inverter_load_# % Calculated thermal load on
drive. Trip point is 100%.
520 527
term_53_analog_# VDC Voltage value on analog input
Terminal 53.
522 529
term_54_analog_# VDC Voltage value on analog input
Terminal 54 (for VLT 6000 only).
523 VLT 6000
only
term_60_analog_# mA Current value on analog input
Terminal 60.
524 531
heatsink_temperature_#
°
C
Drive heatsink temperature. 528 537
operating_hours_# Hour Number of hours power applied
to drive.
600 600
run_hours_# Hour Number of hours drive applied
power to motor.
601 601
kwh_counter_# kWh Output power of drive in hours. 602 602
