Danfoss VLT 6000 Instruction Manual

21
VLT is a registered Danfoss trademark
Appendix
Binary Outputs from Drive (status)
The values in bold are default values.
BACnet
REFERENCE NAME SELECTION
VLT 6000
PARA NO.
VLT 2800
PARA NO.
current_status_#
0=OK
1=Limit 527 534
voltage_status_#
0=OK
1=Limit 527 534
motor_run_status_#
0=Not Running 1=Running
527 534
frequency_status_#
0=Out of Range 1=In
Range
527 534
control_status_# 0=Local
1=Remote
527 534
reference_status_#
0=Not on Ref. 1=On Ref.
527 534
warning_status_#
0=OK 1= Warning
527 534
trip_status_#
0=OK
1=Tripped 527 534
coast_status_# 0=Not Enabled
1=Enabled
527 534
heatsink_temp_#
0=OK
1=Warning
(for VLT 2800 only)
VLT 2800
only
540
vlt2800_term_33_#
0=Off 1=On
(for VLT 2800 only)
VLT 2800
only
528
frequency_low_#
0=OK 1=Warning
531 540
frequency_high_#
0=OK 1=Warning
533 540
current_low_#
0=OK 1=Warning
531 540
current_high_#
0=OK
1=Warning 531 540
feedback_low_#
0=OK
1=Warning 531 540
feedback_high_#
0=OK 1=Warning
531 540
live_zero_error_#
0=OK 1=Warning
531 540
phase_loss_#
0=OK 1=Warning
531 540
drive_therm_overload_#
0=OK
1=Warning 531 540
motor_therm_overload_#
0=OK
1=Warning 531 540
current_limit_#
0=OK 1=Warning
531 540
external_fault_#
(safety interlock)
0=OK 1=Alarm
(for VLT 6000 only)
529 VLT 6000
only
over_temp_#
0=OK 1=Alarm
529 538
earth_fault_#
0=OK 1=Alarm
(for VLT 6000 only)
529 VLT 6000
only
trip_lock_#
0=OK
1=Trip Lock 529 538
standby_#
0=False
1=True
(for VLT 6000 only)
532 VLT 6000
only
jogging_#
0=False
1=True
(for VLT 6000 only)
532 VLT 6000
only
hand_mode_#
0=Auto
1=Hand
(for VLT 6000 only)
532 VLT 6000
only
off_#
0=False 1=True
(for VLT 6000 only)
532 VLT 6000
only
local_ref_#
0=False
1=True
(for VLT 6000 only)
532 VLT 6000
only
running_at_ref_#
0=False 1=True
(for VLT 6000 only)
532 VLT 6000
only
sleep_mode_#
0=False 1=True
(for VLT 6000 only)
532 VLT 6000
only
NOTE: # symbol represents drive ID number.
