5.5.3 F Frame Circuit Breakers
Frame size Power & Voltage Type
F3 P450 380-500V & P630-P710 525-690V Merlin Gerin NPJF36120U31AABSCYP*
F4 P500-P630 380-500V & P800 525-690V Merlin Gerin NRJF36200U31AABSCYP*
F4 P710 380-500V & P900-P1M0 525-690V Merlin Gerin NRJF36200U31AABSCYP*
F4 P800 380-500V Merlin Gerin NRJF36250U31AABSCYP*
* Drive SCCR rating maybe less than 100 kA when this option is added. See the drive label for SCCR rating.
5.5.4 F-Frame Mains Contactors
Frame size Power & Voltage Type
F3 P450-P500 380-500V & P630-P800 525-690V Eaton XTCE650N22A*
F3 P560 380-500V Eaton XTCE820N22A*
F3 P630380-500V Eaton XTCEC14P22B*
F4 P900 525-690V Eaton XTCE820N22A*
F4 P710-P800 380-500V & P1M0 525-690V Eaton XTCEC14P22B*
* Drive SCCR rating maybe less than 100 kA when this option is added. See the drive label for SCCR rating.
5.6 Final Set-Up and Test
To test the set-up and ensure that the frequency converter is running, follow these steps.
Step 1. Locate the motor name plate.
NB!
The motor is either star- (Y) or delta- connected (Δ).
This information is located on the motor name plate
data.
Step 2. Enter the motor name plate data in this parameter list.
To access this list first press the [QUICK MENU] key then select “Q2 Quick
Setup”.
1. Motor Power [kW]
or Motor Power [HP]
par. 1-20
par. 1-21
2. Motor Voltage par. 1-22
3. Motor Frequency par. 1-23
4. Motor Current par. 1-24
5. Motor Nominal Speed par. 1-25
5 How to Install VLT
®
AQUA Drive Design Guide
146 MG.20.N5.02 - VLT
®
is a registered Danfoss trademark
5
