4. Choose “Save as”
All parameters are now stored in the PC.
Load Drive Settings:
1. Connect a PC to the unit via USB com port
2. Open MCT 10 Set-up software
3. Choose “Open”– stored files will be shown
4. Open the appropriate file
5. Choose “Write to drive”
All parameter settings are now transferred to the drive.
A separate manual for MCT 10 Set-up Software is available.
The MCT 10 Set-up Software Modules
The following modules are included in the software package:
MCT 10 Set-up Software
Setting parameters
Copy to and from frequency converters
Documentation and print out of parameter settings incl. diagrams
Ext. User Interface
Preventive Maintenance Schedule
Clock settings
Timed Action Programming
Smart Logic Controller Set-up
Cascade Control Config. Tool
Ordering number:
Please order your CD containing MCT 10 Set-up Software using code number 130B1000.
MCT 10 can also be downloaded from the Danfoss Internet:
WWW.DANFOSS.COM
, Business Area: Motion Controls.
MCT 31
The MCT 31 harmonic calculation PC tool enables easy estimation of the harmonic distortion in a given application. Both the harmonic distortion of Danfoss
frequency converters as well as non-Danfoss frequency converters with different additional harmonic reduction devices, such as Danfoss AHF filters and
12-18-pulse rectifiers, can be calculated.
Ordering number:
Please order your CD containing the MCT 31 PC tool using code number 130B1031.
MCT 31 can also be downloaded from the Danfoss Internet:
WWW.DANFOSS.COM
, Business Area: Motion Controls.
5.10 Safety
5.10.1 High Voltage Test
Carry out a high voltage test by short-circuiting terminals U, V, W, L
1
, L
2
and L
3
. Energize maximum 2.15 kV DC for 380-500V frequency converters and
2.525 kV DC for 525-690V frequency converters for one second between this short-circuit and the chassis.
NB!
When running high voltage tests of the entire installation, interrupt the mains and motor connection if the leakage currents are too
high.
5 How to Install VLT
®
AQUA Drive Design Guide
154 MG.20.N5.02 - VLT
®
is a registered Danfoss trademark
