NB!
Where RFI filters are available, there are two different type of RFI filters depending on the input plate combination and the RFI filters
interchangeable. Field installable kits in certain cases are the same for all voltages.
380 - 480 V
380 - 500 V
Fuses Disconnect Fuses RFI RFI Fuses RFI Disconnect
Fuses
D1 All D1 power sizes 176F8442 176F8450 176F8444 176F8448 176F8446
D2 All D2 power sizes 176F8443 176F8441 176F8445 176F8449 176F8447
E1 FC102/ 202: 315 kW
: 250 kW
176F0253 176F0255 176F0257 176F0258 176F0260
FC102/ 202: 355 - 450 kW
: 315 - 400 kW
176F0254 176F0256 176F0257 176F0259 176F0262
525 - 690 V Fuses Disconnect Fuses RFI RFI Fuses RFI Disconnect
Fuses
D1 FC102/ 202: 45-90 kW
FC302: 37-75 kW
175L8829 175L8828 175L8777 NA NA
FC102/202: 110-160 kW
FC302: 90-132 kW
175L8442 175L8445 175L8777 NA NA
D2 All D2 power sizes 175L8827 175L8826 175L8825 NA NA
E1 FC102/202: 450-500 kW
FC302: 355-400 kW
176F0253 176F0255 NA NA NA
FC102/202: 560-630 kW
FC302: 500-560 kW
176F0254 176F0258 NA NA NA
Kit contents
- Input plate assembled
- Instruction sheet 175R5795
- Modification Label
- Disconnect handle template (units w/ mains disconnect)
Cautions
- Frequency converter contains dangerous voltages when connected to line voltage. No disassembly should be attempted with
power applied
- Electrical parts of the frequency converter may contain dangerous voltages even after the mains have been disconnected.
Wait the minimum time listed on the drive label after disconnecting the mains before touching any internal components to
ensure that capacitors have fully discharged
- The input plates contain metal parts with sharp edges. Use hand protection when removing and reinstalling.
- E frames input plates are heavy (20-35 kg depending on configuration). It is recommended that the disconnect switch be
removed from input plate for easier installation and be reinstalled on the input plate after the input plate has been installed
on the drive
NB!
For further information, please see the Instruction Sheet,
175R5795
3.7.6 Installation of Mains Shield for Frequency Converters
This section is for the installation of a mains shield for the frequency converter series with D1, D2 and E1 frames. It is not possible to install in the IP00/
Chassis versions as these have included as standard a metal cover. These shields satisfy VBG-4 requirements.
VLT
®
AQUA Drive Design Guide 3 VLT AQUA Selection
MG.20.N5.02 - VLT
®
is a registered Danfoss trademark 87
