Danfoss VLT AutomationDrive FC 300 Series User Manual

Table 111: Line Reactor Configuration for D9h–D10h and E5h–E6h Enclosures, 525–690 V
Enclosure
Model
Impedance [%)
D9h
N90K
2.30
D9h
N110
2.78
D9h
N132
3.29
D10h
N160
2.92
D10h
N200
3.67
D10h
N250
3.08
D10h
N315
3.67
E5h
N355
2.89
E5h
N400
3.11
E5h
N500
3.55
E5h
N560
4.04
E6h
N630
3.19
E6h
N710
3.70
10.7.3 dU/dt Filter Specifications
Voltage rating
3x380–690 V
Motor frequency derating, 50 Hz
Nominal
Motor frequency derating, 60 Hz
Nominal
Motor frequency derating, 100 Hz
0.75 x nominal
Minimum switching frequency
No limit
Maximum switching frequency
Nominal switching frequency
Overload capacity
150% for 60 s, every 10 minutes
10.7.4 Sine-wave Filter Specifications
Voltage rating
3x380–500 V and 525–690 V AC
Nominal current @ 50 Hz
212 A and 315 A for 380–500 V, 137 A and 222 A for 525–690 V
(1)
Motor frequency with derating
(1)
Up to 150 Hz
Motor frequency without derating
0–60 Hz
Minimum switching frequency
2 kHz for 380–500 V, 1.5 kHz for 525–690 V
Maximum switching frequency
Nominal switching frequency
Overvoltage category
OVC III as defined in IEC61800-5-1
Overload capacity
150% for 60 s every 10 minutes
Ambient temperature [°C (°F)]
(2)
-15 (5) to +60 (140)
Storage temperature [°C (°F)]
-40 (-40) to +70 (158)
Transport temperature [°C (°F)]
-40 (-40) to +70 (158)
Altitude during operation
100% current (no derating) up to 1000 m (3280 ft)
1% current derating for each 100 m (328 ft) above 1000 m (3280
ft)
AQ262139143212en-000301 / 130R0879178 | Danfoss A/S © 2021.10
Specifications
VLT® AutomationDrive FC 302
Operating Guide
