Table 124: Fusible Disconnect Switches for VLT
®
AutomationDrive FC 302 Enclosed Drive Models N90K–N250, 525–690 V
N90K
N110
N132
N160
N200
N250
IEC
400 A/690 V
400 A/690 V
400 A/690 V
630 A/690 V
630 A/690 V
630 A/690 V
ABB P/N
OS400D30P
OS400D30P
OS400D30P
OS630D30P
OS630D30P
OS630D30P
UL
400 A/600 V
400 A/600 V
400 A/600 V
400 A/600 V
400 A/600 V
600 A/600 V
ABB P/N
OS400J30
OS400J30
OS400J30
OS400J30
OS400J30
OS600J30
Table 125: Fusible Disconnect Switches for VLT
®
AutomationDrive FC 302 Enclosed Drive Models N315–N560, 525–690 V
N315
N355
N400
N500
N560
IEC
630 A/690 V
630 A/690 V
1250 A/690 V
1250 A/690 V
1250 A/690 V
ABB P/N
OS630D30P
OS630D30P
OS1250D30P
OS1250D30P
OS1250D30P
UL
600 A/600 V
600 A/600 V
800 A/600 V
800 A/600 V
800 A/600 V
ABB P/N
OS600J30
OS600J30
OS800L30
OS800L30
OS800L30
Table 126: Fusible Disconnect Switches for VLT
®
AutomationDrive FC 302 Enclosed Drive Models N630–N710, 525–690 V
N630
N710
IEC
1250 A/690 V
1250 A/690 V
ABB P/N
OS1250D30P
OS1250D30P
UL
1200 A/600 V
1200 A/600 V
ABB P/N
OS1200L30
OS1200L30
10.8.4 Non-fusible Disconnect Switches
The non-fusible disconnector switch is an option. All units ordered and supplied with a factory-installed, non-fusible disconnect
switch require a UL Class fuse to meet 65kA SCCR for the drive system.
Table 127: Non-fusible Disconnect Switches for VLT
®
AutomationDrive FC 302 Enclosed Drive Models N90K–N250, 380–500 V
N90K
N110
N132
N160
N200
N250
IEC
400 A/690 V
400 A/690 V
400 A/690 V
630 A/690 V
630 A/690 V
630 A/690 V
ABB P/N
OT400E30
OT400E30
OT400E30
OT630E30
OT630E30
OT630E30
UL
400 A/600 V
400 A/600 V
400 A/600 V
600 A/600 V
600 A/600 V
800 A/600 V
ABB P/N
OT400U30
OT400U30
OT400U30
OT600U30
OT600U30
OT800U30
Table 128: Non-fusible Disconnect Switches for VLT
®
AutomationDrive FC 302 Enclosed Drive Models N315–N500, 380–500 V
N315
N355
N400
N450
N500
IEC
1000 A/690 V
1000 A/690 V
1250 A/690 V
1250 A/690 V
1250 A/690 V
ABB P/N
OT1000E30
OT1000E30
OT1250E30
OT1250E30
OT1250E30
UL
800 A/600 V
1200 A/600 V
1200 A/600 V
1200 A/600 V
1200 A/600 V
ABB P/N
OT800U30
OT1200U30
OT1200U30
OT1200U30
OT1200U30
AQ262139143212en-000301 / 130R0879 | 183Danfoss A/S © 2021.10
