Danfoss VLT AutomationDrive FC 300 Series User Manual

Table 157: Power Losses for dU/dt Filter Option, 525–690 V
Model
525–550 V [W]
551–690 V [W]
–
NO
HO
NO
HO
N90K
453
308
414
281
N110
204
146
187
134
N132
314
204
287
187
N160
498
314
456
287
N200
302
211
277
193
N250
427
302
390
277
N315
575
427
527
390
N355
800
565
733
523
N400
989
666
905
608
N500
585
450
535
412
N560
654
585
654
535
N630
959
715
878
654
N710
1430
1054
1308
964
11.6.8 Sine-wave Filter Losses
Table 158: Power Losses for Sine-wave Filter Option, 380–500 V
Model
380–440 V [W]
441–500 V [W]
–
NO
HO
NO
HO
N90K
1050
732
843
598
N110
770
512
656
411
N132
1130
770
1039
656
N160
1823
1159
1522
1065
N200
1312
888
1117
742
N250
1969
1312
1630
1117
N315
2529
2103
2033
1703
N355
3242
2529
2685
2033
N400
3738
2821
3112
2685
N450
2205
1822
1732
1517
N500
2790
2205
2255
1732
AQ262139143212en-000301 / 130R0879204 | Danfoss A/S © 2021.10
