Danfoss VLT AutomationDrive FC 300 Instruction Manual

Frame Size
A1 A2 A3 A4 A5 B1 B2 B3 B4 C1 C2 C3 C4
Rated Power in HP [kW]
200–240 V
0.34–2
[0.25–1.5]
0.34–3 [0.25–
2.2]
4–5 [3–3.7]
0.34–3
[0.25–
2.2]
0.34–5
[0.25–3.7]
7.5–10
[5.5–7.5]
11
7.5–10
[5.5–
7.5]
11-15 15-22 30-37
25–30
[18.5–22]
30-37
380– 480/500 V
0.5–2
[0.37–1.5]
0.5–5.5 [0.37–
4.0]
7.5–10 [5.5–
7.5]
0.5–5.5
[0.37–4]
0.5–10
[0.37–7.5]
11-15
25–30
[18.5–
22]
11-15
25–40
[18.5–
30]
30-45 55-75 37-45 55-75
525–600 V
1–10 [0.75–
7.5]
1–10
[0.75–7.5]
11-15
25–30
[18.5–
22]
11-15
25–40
[18.5–
30]
30-45 55-90 37-45 55-90
525–690 V 11-22 30-75
IP NEMA
20
Chassis
20
Chassis
21
Type 1
20
Chassis
21
Type 1
55/66
Type 12
55/66
Type 12
21/ 55/66
Type 1/
Type 12
21/55/66
Type 1/
Type 12
20
Chassis
20
Chassis
21/55/66
Type 1/
Type 12
21/55/66
Type 1/
Type 12
20
Chassis
20
Chassis
Height
Height of backplate A
7.87 in [200
mm]
10.55 in
[268
mm]
14.76 in
[375 mm]
10.55
in [268
mm]
14.76 in
[375
mm]
15.35 in
[390 mm]
16.54 in
[420 mm]
18.90 in
[480 mm]
25.59 in
[650 mm]
15.71 in
[399 mm]
20.47 in
[520 mm]
26.77 in
[680 mm]
30.32 in
[770 mm]
21.65 in [550
mm]
25.98 in
[660 mm]
Height with de-coupling plate for serial commu- nication bus cables
A
12.44 in
[316 mm]
14.72 in
[374
mm]
14.72
in [374
mm]
-- - - -
16.54 in
[420 mm]
23.43 in
[595 mm]
24.80 in [630
mm]
31.50 in
[800 mm]
Distance between mounting holes
a
7.48 in [190
mm]
10.12 in
[257
mm]
13.78 in
[350 mm]
10.12
in [257
mm]
13.78 in
[350
mm]
15.79 in
[401 mm]
15.83 in
[402 mm]
17.87 in
[454 mm]
24.57 in
[624 mm]
14.96 in
[380 mm]
19.49 in
[495 mm]
25.51 in
[648 mm]
29.09 in
[739 mm]
20.51 in [521
mm]
24.84 in
[631 mm]
Width
Width of backplate B
2.95 in [75
mm]
3.54 in
[90
mm]
3.54 in
[90 mm]
5.12 in
[130
mm]
5.12 in
[130
mm]
7.87 in [200
mm]
9.53 in [242
mm]
9.53 in [242
mm]
9.53 in
[242 mm]
6.50 in
[165 mm]
9.06 in
[230 mm]
12.13 in
[308 mm]
14.57 in
[370 mm]
12.13 in [308
mm]
14.57 in
[370 mm]
Width of backplate with one C option
B
5.12 in
[130
mm]
5.12 in
[130 mm]
6.69 in
[170
mm]
6.69 in
[170
mm]
9.53 in [242
mm]
9.53 in [242
mm]
9.53 in
[242 mm]
8.07 in
[205 mm]
9.06 in
[230 mm]
12.13 in
[308 mm]
14.57 in
[370 mm]
12.13 in [308
mm]
14.57 in
[370 mm]
Width of backplate with two C options
B
5.91 in
[150
mm]
5.91 in
[150 mm]
7.48 in
[190
mm]
7.48 in
[190
mm]
9.53 in [242
mm]
9.53 in [242
mm]
9.53 in
[242 mm]
8.86 in
[225 mm]
9.06 in
[230 mm]
12.13 in
[308 mm]
14.57 in
[370 mm]
12.13 in [308
mm]
14.57 in
[370 mm]
Distance between mounting holes
b
2.36 in [60
mm]
2.76 in
[70
mm]
2.76 in
[70 mm]
4.33 in
[110
mm]
4.33 in
[110
mm]
6.73 in [171
mm]
8.47 in [215
mm]
8.27 in [210
mm]
8.27 in
[210 mm]
5.51 in
[140 mm]
7.87 in
[200 mm]
10.71 in
[272 mm]
13.15 in
[334 mm]
10.63 in [270
mm]
12.99 in
[330 mm]
Depth Depth without option A/ B
C
8.15 in [207
mm]
8.07 in
[205
mm]
8.15 in
[207 mm]
8.07 in
[205
mm]
8.15 in
[207
mm]
6.89 in [175
mm]
7.68 in [195
mm]
10.24 in
[260 mm]
10.24 in
[260 mm]
9.80 in
[249 mm]
9.53 in
[242 mm]
12.21 in
[310 mm]
13.19 in
[335 mm]
13.11 in [333
mm]
13.11 in
[333 mm]
With option A/B C
8.74 in [222
mm]
8.66 in
[220
mm]
8.74 in
[222 mm]
8.66 in
[220
mm]
8.74 in
[222
mm]
6.89 in [175
mm]
7.68 in [195
mm]
10.24 in
[260 mm]
10.24 in
[260 mm]
10.32 in
[262 mm]
9.53 in
[242 mm]
12.21 in
[310 mm]
13.19 in
[335 mm]
13.11 in [333
mm]
13.11 in
[333 mm]
VLT
®
AutomationDrive FC 300 Instruction
Manual
3 How to Install
MG.33.AG.22 - VLT
®
is a registered Danfoss trademark 3-3
3
