Frame Size
A1 A2 A3 A4 A5 B1 B2 B3 B4 C1 C2 C3 C4
Screw holes
c
0.24 in [6.0
mm]
0.32 in
[8.0
mm]
0.32 in
[8.0 mm]
0.32 in
[8.0
mm]
0.32 in
[8.0
mm]
0.33 in
[8.25 mm]
0.33 in
[8.25 mm]
0.47 in [12
mm]
0.47 in [12
mm]
0.32 in [8
mm]
0.49 in
[12.5 mm]
0.49 in
[12.5 mm]
d
ø0.35 in. [8
mm]
ø0.43 in
[11
mm]
ø0.43 in
[11 mm]
ø0.43
in [11
mm]
ø0.43 in
[11 mm]
ø0.47 in [12
mm]
ø0.47 in [12
mm]
ø0.75 in [19
mm]
ø0.75 in
[19 mm]
0.47 in
[12 mm]
ø0.75 in
[19 mm]
ø0.75 in
[19 mm]
e
ø0.20 in [5
mm]
ø0.22 in
[5.5
mm]
ø0.22 in
[5.5 mm]
ø0.22
in [5.5
mm]
ø0.22 in
[5.5
mm]
ø0.26 in
(6.5 mm)
ø0.26 in
(6.5 mm)
ø0.35 in [9
mm]
ø0.35 in [9
mm]
0.27 in
[6.8 mm]
0.34 in [8.5
mm]
ø0.35 in [9
mm]
ø0.35 in [9
mm]
0.34 in [8.5
mm]
0.34 in [8.5
mm]
f
0.20 in [5
mm]
0.35 in
[9 mm]
0.35 in [9
mm]
0.35 in
[9 mm]
0.35 in
[9 mm]
0.24 in [6
mm]
0.35 in [9
mm]
0.35 in [9
mm]
0.35 in [9
mm]
0.31 in
[7.9 mm]
0.59 in [15
mm]
0.39 in
[9.8 mm]
0.39 in
[9.8 mm]
0.67 in [17
mm]
0.67 in [17
mm]
Max weight
5.95 lbs [2.7
kg]
10.8 lbs
[4.9 kg]
11.69 lbs
[5.3 kg]
14.55
lbs [6.6
kg]
15.43
lbs [7.0
kg]
21.38 lbs
[9.7 kg]
29.76/31.31
lbs
[13.5/14.2
kg]
50.71 lbs
[23 kg]
59.53 lbs
[27 kg]
26.46 lbs
[12 kg]
51.81 lbs
[23.5 kg]
99.21 lbs
[45 kg]
143.30 lbs
[65 kg]
77.16 lbs [35
kg]
110.23 lbs
[50 kg]
