Figure 3.11: Motor connection for size B1 and B2 (IP 21/
NEMA Type 1, IP 55/ NEMA Type 12 and IP66/ NEMA Type
4X)
Figure 3.12: Motor connection for size B3.
Figure 3.13: Motor connection for frame size B4 .
3 How to Install
VLT
®
AutomationDrive FC 300 Instruction
Manual
3-14
MG.33.AG.22 - VLT
®
is a registered Danfoss trademark
3
