NOTE!
Digital input should be set to [0]
PNP - Active at 24V
in par. 5-00.
2-10 Brake Function
Option: Function:
[0] * Off No brake resistor is installed.
[1] Resistor brake A brake resistor is incorporated in the system, for dissipating surplus brake energy as heat. Con-
necting a brake resistor allows a higher DC link voltage during braking (generating operation). The
resistor brake function is only active in adjustable frequency drives with an integral dynamic brake.
[2] AC brake Is selected to improve braking without using a brake resistor. This parameter controls an overmag-
netization of the motor when running with a generatoric load. This function can improve the OVC
function. Increasing the electrical losses in the motor allows the OVC function to increase the braking
torque without exceeding the overvoltage limit. Please note that AC brake is not as effective as
dynamic breaking with resistor.
AC brake is for VVC
+
and flux mode in both open-loop and closed-loop.
2-11 Brake Resistor (ohm)
Range: Function:
Application
dependent*
[Application dependant] Set the brake resistor value in Ohms. This value is used for monitoring the power to the brake
resistor in par. 2-13
Brake Power Monitoring
. This parameter is only active in adjustable frequency
drives with an integral dynamic brake.
Use this parameter for values without decimals. For a selection with two decimals, use
par. 30-81
Brake Resistor (ohm)
.
2-12 Brake Power Limit (kW)
Range: Function:
Application
dependent*
[Application dependant] Set the monitoring limit of the braking energy transmitted to the resistor.
The monitoring limit is a product of the maximum duty cycle (120 sec.) and the maximum power
of the brake resistor at that duty cycle. See the formula below.
For 200–240 V units:
P
resistor
=
390
2
×
dutytime
R
× 120
[W]
For 380–480 V units
P
resistor
=
778
2
×
dutytime
R
× 120
[W]
For 380–500 V units
P
resistor
=
810
2
×
dutytime
R
× 120
[W]
For 575–600 V units
P
resistor
=
943
2
×
dutytime
R
× 120
[W]
This parameter is only active in adjustable frequency drives with an integral dynamic brake.
4 How to Program
VLT
®
AutomationDrive FC 300 Instruction
Manual
4-10
MG.33.AG.22 - VLT
®
is a registered Danfoss trademark
4
