4.1.3 Initial Commissioning
The easiest way of carrying out the initial commissioning is by using the Quick Menu button and follow the quick set-up procedure using LCP 102 (read
table from left to right). The example applies to open loop applications:
Press
Q2 Quick Menu
Par. 0-01 Language Set language
Par. 1-20 Motor Power [kW] Set Motor nameplate power
Par. 1-22
Motor Voltage Set Nameplate voltage
Par. 1-23 Motor Frequency Set Nameplate frequency
Par. 1-24
Motor Current Set Nameplate current
Par. 1-25 Motor Nominal Speed Set Nameplate speed in RPM
Par. 5-12
Terminal 27 Digital Input
If terminal default is Coast inverse it is possible to change this
setting to
No function . No connection to terminal 27 is then
needed for running AMA
Par. 1-29 Automatic Motor Adaptation
(AMA)
Set desired AMA function. Enable complete AMA is recommen-
ded
Par. 3-02
Minimum Reference Set the minimum speed of the motor shaft
Par. 3-03 Maximum Reference Set the maximum speed of the motor shaft
Par. 3-41
Ramp 1 Ramp up Time
Set the ramping up time with reference to synchronous motor
speed, n
s
Par. 3-42 Ramp 1 Ramp Down Time
Set the ramping downdecel time with reference to synchronous
motor speed, n
s
Par. 3-13
Reference Site Set the site from where the reference must work
4 How to Programme
VLT
®
AutomationDrive FC 300 Operating
Instructions
44 MG.33.AG.02 - VLT
®
is a registered Danfoss trademark
4
