4.4.15 15-** Drive Information
Par.
No.
#
Parameter description Default value 4-set-up FC 302
only
Change dur-
ing operation
Conver-
sion index
Type
15-0* Operating Data
15-0
0 Operating Hours 0 h All set-ups FALSE 74 Uint32
15-0
1
Running Hours 0 h All set-ups FALSE 74 Uint32
15-0
2 kWh Counter 0 kWh All set-ups FALSE 75 Uint32
15-0
3
Power Up's 0 N/A All set-ups FALSE 0 Uint32
15-0
4Over Temp's 0 N/A All set-ups FALSE 0 Uint16
15-0
5
Over Volt's 0 N/A All set-ups FALSE 0 Uint16
15-0
6 Reset kWh Counter [0] Do not reset All set-ups TRUE - Uint8
15-0
7
Reset Running Hours Counter [0] Do not reset All set-ups TRUE - Uint8
15-1* Data Log Settings
15-1
0
Logging Source 0 2 set-ups TRUE - Uint16
15-1
1 Logging Interval SR 2 set-ups TRUE -3 TimD
15-1
2
Trigger Event [0] False 1 set-up TRUE - Uint8
15-1
3 Logging Mode [0] Log always 2 set-ups TRUE - Uint8
15-1
4
Samples Before Trigger 50 N/A 2 set-ups TRUE 0 Uint8
15-2* Historic Log
15-2
0
Historic Log: Event 0 N/A All set-ups FALSE 0 Uint8
15-2
1 Historic Log: Value 0 N/A All set-ups FALSE 0 Uint32
15-2
2
Historic Log: Time 0 ms All set-ups FALSE -3 Uint32
15-3* Fault Log
15-3
0
Fault Log: Error Code 0 N/A All set-ups FALSE 0 Uint8
15-3
1 Fault Log: Value 0 N/A All set-ups FALSE 0 Int16
15-3
2
Fault Log: Time 0 s All set-ups FALSE 0 Uint32
15-4* Drive Identification
15-4
0
FC Type 0 N/A All set-ups FALSE 0 VisStr[6]
15-4
1 Power Section 0 N/A All set-ups FALSE 0 VisStr[20]
15-4
2
Voltage 0 N/A All set-ups FALSE 0 VisStr[20]
15-4
3 Software Version 0 N/A All set-ups FALSE 0 VisStr[5]
15-4
4
Ordered Typecode String 0 N/A All set-ups FALSE 0 VisStr[40]
15-4
5 Actual Typecode String 0 N/A All set-ups FALSE 0 VisStr[40]
15-4
6
Frequency Converter Ordering No 0 N/A All set-ups FALSE 0 VisStr[8]
15-4
7 Power Card Ordering No 0 N/A All set-ups FALSE 0 VisStr[8]
15-4
8
LCP Id No 0 N/A All set-ups FALSE 0 VisStr[20]
15-4
9 SW ID Control Card 0 N/A All set-ups FALSE 0 VisStr[20]
15-5
0
SW ID Power Card 0 N/A All set-ups FALSE 0 VisStr[20]
15-5
1 Frequency Converter Serial Number 0 N/A All set-ups FALSE 0 VisStr[10]
15-5
3
Power Card Serial Number 0 N/A All set-ups FALSE 0 VisStr[19]
15-5
9 CSIV Filename SR 1 set-up FALSE 0 VisStr[16]
15-6* Option Ident
15-6
0 Option Mounted 0 N/A All set-ups FALSE 0 VisStr[30]
15-6
1
Option SW Version 0 N/A All set-ups FALSE 0 VisStr[20]
15-6
2 Option Ordering No 0 N/A All set-ups FALSE 0 VisStr[8]
15-6
3
Option Serial No 0 N/A All set-ups FALSE 0 VisStr[18]
15-7
0 Option in Slot A 0 N/A All set-ups FALSE 0 VisStr[30]
15-7
1
Slot A Option SW Version 0 N/A All set-ups FALSE 0 VisStr[20]
15-7
2 Option in Slot B 0 N/A All set-ups FALSE 0 VisStr[30]
VLT
®
AutomationDrive FC 300 Operating
Instructions
4 How to Programme
MG.33.AG.02 - VLT
®
is a registered Danfoss trademark
85
4
