Danfoss VLT AutomationDrive FC 302 Instruction Manual

6.3.17 16-** Data Readouts
Par.
No. #
Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
16-0* General Status
16-00 Control Word 0 N/A All set-ups FALSE 0 V2
16-01 Reference [Unit] 0 ReferenceFeedbackUnit All set-ups FALSE -3 Int32
16-02 Reference % 0 % All set-ups FALSE -1 Int16
16-03 Status Word 0 N/A All set-ups FALSE 0 V2
16-05 Main Actual Value [%] 0 % All set-ups FALSE -2 N2
16-09 Custom Readout 0 CustomReadoutUnit All set-ups FALSE -2 Int32
16-1* Motor Status
16-10 Power [kW] 0 kW All set-ups FALSE 1 Int32
16-11 Power [hp] 0 hp All set-ups FALSE -2 Int32
16-12 Motor voltage 0 V All set-ups FALSE -1 Uint16
16-13 Frequency 0 Hz All set-ups FALSE -1 Uint16
16-14 Motor current 0 A All set-ups FALSE -2 Int32
16-15 Frequency [%] 0 % All set-ups FALSE -2 N2
16-16 Torque [Nm] 0 Nm All set-ups FALSE -1 Int16
16-17 Speed [RPM] 0 RPM All set-ups FALSE 67 Int32
16-18 Motor Thermal 0 % All set-ups FALSE 0 Uint8
16-19 KTY sensor temperature 0 °C All set-ups FALSE 100 Int16
16-20 Motor Angle 0 N/A All set-ups TRUE 0 Uint16
16-21 Torque [%] High Res. 0 % All set-ups FALSE -1 Int16
16-22 Torque [%] 0 % All set-ups FALSE 0 Int16
16-23 Motor Shaft Power [kW] 0 kW All set-ups TRUE 1 Int32
16-24 Calibrated Stator Resistance 0.0000 Ohm All set-ups x TRUE -4 Uint32
16-25 Torque [Nm] High 0 Nm All set-ups FALSE -1 Int32
16-3* Drive Status
16-30 DC Link Voltage 0 V All set-ups FALSE 0 Uint16
16-32 Brake Energy /s 0 kW All set-ups FALSE 0 Uint32
16-33 Brake Energy /2 min 0 kW All set-ups FALSE 0 Uint32
16-34 Heatsink Temp. 0 °C All set-ups FALSE 100 Uint8
16-35 Inverter Thermal 0 % All set-ups FALSE 0 Uint8
16-36 Inv. Nom. Current ExpressionLimit All set-ups FALSE -2 Uint32
16-37 Inv. Max. Current ExpressionLimit All set-ups FALSE -2 Uint32
16-38 SL Controller State 0 N/A All set-ups FALSE 0 Uint8
16-39 Control Card Temp. 0 °C All set-ups FALSE 100 Uint8
16-40 Logging Buffer Full [0] No All set-ups TRUE - Uint8
16-41 LCP Bottom Statusline 0 N/A All set-ups TRUE 0 VisStr[50]
16-45 Motor Phase U Current 0 A All set-ups TRUE -2 Int32
16-46 Motor Phase V Current 0 A All set-ups TRUE -2 Int32
16-47 Motor Phase W Current 0 A All set-ups TRUE -2 Int32
16-48 Speed Ref. After Ramp [RPM] 0 RPM All set-ups FALSE 67 Int32
16-49 Current Fault Source 0 N/A All set-ups x TRUE 0 Uint8
16-5* Ref. & Feedb.
16-50 External Reference 0 N/A All set-ups FALSE -1 Int16
16-51 Pulse Reference 0 N/A All set-ups FALSE -1 Int16
16-52 Feedback [Unit] 0 ReferenceFeedbackUnit All set-ups FALSE -3 Int32
16-53 Digi Pot Reference 0 N/A All set-ups FALSE -2 Int16
16-57 Feedback [RPM] 0 RPM All set-ups FALSE 67 Int32
16-6* Inputs & Outputs
16-60 Digital Input 0 N/A All set-ups FALSE 0 Uint16
16-61 Terminal 53 Switch Setting [0] Current All set-ups FALSE - Uint8
16-62 Analog Input 53 0 N/A All set-ups FALSE -3 Int32
16-63 Terminal 54 Switch Setting [0] Current All set-ups FALSE - Uint8
16-64 Analog Input 54 0 N/A All set-ups FALSE -3 Int32
16-65 Analog Output 42 [mA] 0 N/A All set-ups FALSE -3 Int16
16-66 Digital Output [bin] 0 N/A All set-ups FALSE 0 Int16
16-67 Freq. Input #29 [Hz] 0 N/A All set-ups x FALSE 0 Int32
16-68 Freq. Input #33 [Hz] 0 N/A All set-ups FALSE 0 Int32
Programming Instruction Manual
100 Danfoss A/S © Rev. 2014-02-07 All rights reserved. MG37A222
66
