6.4.3 8-** Comm. and Options
Par. No. # Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
8-0* General Settings
8-01 Control site [0] Digital and ctrl.word All set-ups TRUE - Uint8
8-02 Control word source null All set-ups TRUE - Uint8
8-03 Control word timeout time 1.0 s 1 set-up TRUE -1 Uint32
8-04 Control word timeout function [0] Off 1 set-up TRUE - Uint8
8-05 End-of-timeout function [1] Resume set-up 1 set-up TRUE - Uint8
8-06 Reset control word timeout [0] Do not reset All set-ups TRUE - Uint8
8-3* FC Port Settings
8-30 Protocol [1] FC MC 1 set-up TRUE - Uint8
8-31 Address 2 N/A 1 set-up TRUE 0 Uint8
8-32 FC port baud rate [2] 9600 Baud 1 set-up TRUE - Uint8
8-33 Parity/stop bits
[0] Even parity, [1] Stop
bit All set-ups TRUE Uint8
8-35 Minimum response delay 10 ms All set-ups TRUE -3 Uint16
8-36 Max response delay 5000 ms 1 set-up TRUE -3 Uint16
8-37 Max inter-char delay 25 ms 1 set-up TRUE -3 Uint16
8-4* FC MC Protocol Set
8-42 PCD write configuration [1685] FC port CTW 1 All set-ups TRUE Uint16
8-43 PCD read configuration [1603] Status word All set-ups TRUE Uint16
8-5* Digital/Bus
8-53 Start select [3] Logic OR All set-ups TRUE - Uint8
8-55 Set-up select [3] Logic OR All set-ups TRUE - Uint8
Programming Instruction Manual
112 Danfoss A/S © Rev. 2014-02-07 All rights reserved. MG37A222
