6.4.7 300-** AF Settings
NOTICE!
Except for 300-10 Active Filter Nominal Voltage, it is not recommended to change the settings in this parameter group
for the Low Harmonic Drive
Par. No. # Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
300-0* General Settings
300-00 Harmonic cancellation mode [0] Overall All set-ups TRUE - Uint8
300-01 Compensation priority [0] Harmonics All set-ups TRUE - Uint8
300-08 Lagging reactive current [0] Disabled All set-ups FALSE Uint8
300-1* Network Settings
300-10 Active filter nominal voltage ExpressionLimit 2 set-ups FALSE 0 Uint32
300-2* CT Settings
300-20 CT primary rating ExpressionLimit 2 set-ups FALSE 0 Uint32
300-24 CT Sequence [0] L1, L2, L3 2 set-ups FALSE - Uint8
300-25 CT Polarity [0] Normal 2 set-ups FALSE - Uint8
300-26 CT Placement [1] Load Current 2 set-ups FALSE - Uint8
300-27 Number of CTs per phase 1 All set-ups FALSE Uint8
300-29 Start auto CT detection [0] Off All set-ups FALSE - Uint8
300-3* Compensation
300-30 Compensation points 0.0 A All set-ups TRUE -1 Uint32
300-35 Cosphi reference 0.500 N/A All set-ups TRUE -3 Uint16
300-4* Paralleling
300-40 Master follower selection [2] Not Paralleled 2 set-ups FALSE - Uint8
300-41 Follower ID 1 N/A 2 set-ups FALSE 0 Uint32
300-42 Num. of follower AFs 1 N/A 2 set-ups FALSE 0 Uint32
300-5* Sleep Mode
300-50 Enable sleep mode null 2 set-ups TRUE - Uint8
300-51 Sleep mode trig source [0] Mains current All set-ups TRUE - Uint8
300-52 Sleep mode wake up trigger ExpressionLimit All set-ups TRUE 0 Uint32
300-53 Sleep mode sleep trigger 80 % All set-ups TRUE 0 Uint32
Programming Instruction Manual
MG37A222 Danfoss A/S © Rev. 2014-02-07 All rights reserved. 117
