Danfoss VLT AutomationDrive FC 302

1
2
3
4
5
130BX334.11
1 Contactor 4 Circuit breaker or disconnect (if purchased)
2 RFI filter 5 AC line power/line fuses (if purchased)
3 Line power AC power input terminals
Figure 2.5 Frame Size F18 Options Cabinet
*The options cabinet is not optional for the LHD. The ancillary equipment is stored in the cabinet.
