Danfoss VLT AutomationDrive FC 302 Instruction Manual

No. Description Warning Alarm/Trip Alarm/Trip Lock Parameter Reference
1 10 Volts low X
2 Live zero error (X) (X) 6-01
4 Mains phase loss X
5 DC link voltage high X
6 DC link voltage low X
7 DC overvoltage X X
8 DC undervoltage X X
13 Overcurrent X X X
14 Ground fault X X X
15 Hardware mismatch X X
16 Short-circuit X X
17 Control word timeout (X) (X) 8-04
23 Internal fan fault X
24 External fan fault X 14-53
29 Heatsink temp X X X
33 Inrush fault X X
34 Fieldbus fault X X
35 Option fault X X
38 Internal fault
39 Heatsink sensor X X
40 Overload of digital output terminal 27 (X) 5-00, 5-01
41 Overload of digital output terminal 29 (X) 5-00, 5-02
46 Pwr. card supply X X
47 24 V supply low X X X
48 1.8 V supply low X X
65 Control board overtemperature X X X
66 Heatsink temperature low X
67 Option configuration has changed X
68 Safe torque off activated
X
1)
69 Pwr. card temp X X
70 Illegal FC configuration X
72 Dang. failure
X
1)
73 Safe torque off auto restart
76 Power unit set-up X
79 Illegal PS config X X
80 Unit initialized to default value X
244 Heatsink temp X X X
245 Heatsink sensor X X
246 Pwr.card supply X X
247 Pwr.card temp X X
248 Illegal PS config X X
250 New spare part X
251 New type code X X
300 Mains cont. fault X
301 SC cont. fault X
302 Cap. overcurrent X X
303 Cap. ground fault X X
304 DC overcurrent X X
305 Mains freq. limit X
308 Resistor temp X X
Warnings and Alarms Instruction Manual
