Danfoss VLT AutomationDrive FC 302 Design Guide

FC 300 Design Guide
How to Program
Pulse output #29 [Hz] [1670] returns the
actual value of impulses applied to terminal
29 in digital output mode.
Fieldbus CTW 1 [1680] Control word (CTW)
received from the Bus-Master.
Fieldbus status word1 signal [1681] Status
word (STW) sent to the Bus-Master.
Fieldbus REF 1 [1682] Main reference value sent
with control word form the Bus-Master.
Fieldbus speed actual value A signal
[1683] Main actual value send with the Status
word to the Bus Master.
Comm. Option Status [binary] [1684] Extended
fieldbus comm. option status word.
FC Port CTW 1 [1685] Control word (CTW)
received from the Bus-Master.
FC Port REF 1 [1686] Status word (STW)
sent to the Bus-Master.
0-21 Display Line 1.2 Small
Option:
*
Motor Current [A] [1614]
Optionsarethesameasinpar.0-20.
0-22 Display Line 1.3 Small
*
Power [kW] [1610]
0-23 Display Line 2 Large
*
Frequency [Hz] [1613]
0-24 Display Line 3 Large
*
Reference % [1602]
Option:
None [0]
Control Word [1600]
Reference [Unit] [1601]
Reference % [1602]
Status Word [binary] [1603]
Alarm Word [1604]
Warning Word [1605]
Extended Status Word [1606]
Power [kW] [1610]
Power [hp] [1611]
Motor Voltage [V] [1612]
Frequency [Hz] [1613]
Motor Current [A] [1614]
Torque [%] [1616]
Speed [RPM] [1617]
Motor thermal [1618]
DC Link Voltage [V] [1630]
BrakeEnergy/s [1632]
Heatsink Temperature [°C] [1634]
Inverter thermal [1635]
InomVLT [1636]
ImaxVLT [1637]
Condition controller state [1638]
Data read-out: Control Card Temperature [1639]
External Reference [%] [1650]
Feedback [Unit] [1652]
Digital Input [1660]
Terminal 53 Switch Setting [1661]
Analog Input 53 [1662]
Terminal 54 Switch Setting [1663]
Analog Input 54 [1664]
Analog Output 42 [mA] [1665]
Digital Output [bin] [1666]
Frequency input #29 [Hz] [1667]
Frequency input #33 [Hz] [1668]
Pulse output #27 [Hz] [1669]
Pulse output #29 [Hz] [1670]
Pulse output #29 [Hz] [1670]
Fieldbus control word1 signal [1680]
Fieldbus status word1 signal [1681]
Fieldbus speed setpoint A signal [1682]
Fieldbus speed actual value A signal [1683]
Communication Option Status Word
[binary]
[1684]
FC port control word1 signal [1685]
FC port speed setpoint A signal [1686]
Function:
None [0] No display value chosen
Control Word [1600] Displays the
present control word
Reference [Unit] [1601] displays the status value
of terminals 53 or 54 using the unit stated on the
basis of configuration in P.1-00 (RPM or Nm).
Reference % [1602] displays the total
reference (sum of digital/analog/pre set /bus/freeze
ref./catch up and slow-down).
Status Word [binary] [1603] Displays
the present status word
Alarm Word [1604] indicates one or several
alarms in a Hex code.
Warning Word [1605] indicates one or
more warnings in a Hex code.
Extended Status Word [1606] [Hex] indicates
one or more stat us states in a Hex code.
Power [kW] [1610] states the actual power
consumed by the motor in kW.
*
default setting ()display text []value for use in communication via serial communication port
136
MG.33.B
3.22 - VLT is a registered Danfoss trademark
