Danfoss VLT AutomationDrive FC 302 Design Guide

FC 300 Design Guide
How to Program
" 1-2* Motor D ata
1-20 Motor Power [kW]
Range:
0.50 - 10 HP (0.37-7.5 kW) [Motor
type de-
pendent]
Function:
The value should equal the nameplate data on the
connected motor. The default value corresp onds
to the nom inal rated out put of the unit.
NOTE
Changing the value in this parameter
affects the setting of other parameters.
Par. 1-20 cannot be changed while
the motor is running.
1-21 Motor Power [HP]
Range:
0.5-10 HP [M-TYPE]
Function:
The value should equal the nameplate data on the
connected motor. The de fa ult setting corresponds
to the nom inal rated out put of the unit.
1-22 Motor Voltage
Range:
200-500 V [Motor
type de-
pendent]
Function:
The value should equal the nameplate data on the
connected motor. The default value corresp onds
to the nom inal rated out put of the unit.
NOTE
Changing the value in this parameter
affects the setting of other parameters.
Par. 1-22 cannot be changed while
the motor is running.
1-23 Motor Frequency
Option:
*
50 Hz (50 HZ) [50]
60 Hz (60 HZ) [60]
Min - Max motor frequency: 20 - 300 Hz
Function:
Select the stated value from the motor name plate.
Alternatively, set the value for motor freq u ency to
be infinitely variable. If a value different from 50 H z
or 60 Hz is selected, it is necessary to correct par.
1-50 to 1-54 . For 87 Hz operation with 230/400 V
motors, set the name plate data for 230 V/50 Hz.
Adapt par. 2-02 Output s peed high limit and par.
2-05 Maximum reference to the 87 Hz application.
NOTE
Changing the value in this parameter
affects the setting of other parameters.
Par. 1-23 cannot be changed while
the motor is running.
NOTE
If a delta connection is used, select
the rated motor freque ncy for the
delta connection.
1-24 Motor Current
Range:
Motor type dependent.
Function:
The value should equal the nameplate data on
the connected motor. Data is used for calculating
torque, motor protection, etc.
NOTE
Changing the value in this parameter
affects the setting of other parameters.
Par. 1-24 cannot be changed while
the motor is running.
1-25 Motor Nominal Speed
Range:
100. - 60000. RPM
*
ExpressionLimitRPM
Function:
The value should equal the name plate data
ontheconnectedmotor. Thedataisuse
dfor
calculating motor compensations.
1-26 Motor Cont. Rated Torque
Range:
1.0 - 10 000.0 Nm
*
5.0Nm
*
default setting ()display text []value for use in communication via serial communication port
141
MG.33.B
3.22 - VLT is a registered Danfoss trademark
