3.2.2 Conguring the CANopen Master
The following example shows the details in setting up the CANopen conguration on a Moeller XC-CPU201 PLC.
Illustration 3.5 Setting up the Baud Rate and Node-ID on the CanMaster (CANopen Scanner)
130BA936.10
Illustration 3.6 Appending a CANopen Node, from EDS File Library, by Rght-clicking CanMaster
Conguration Programming Guide
