6.16 Parameter Lists
Changes during operation
”TRUE” means that the parameter can be changed while
the frequency converter is in operation. “FALSE” means
that the frequency converter must be stopped before a
change can be made.
4-Set-up
'All set-ups': the parameter can be set individually in each
of the four set-ups, i. e. one single parameter can have
four different data values.
’1 set-up’: data value will be the same in all set-ups.
Data
type
Description Type
2 Integer 8 Int8
3 Integer 16 Int16
4 Integer 32 Int32
5 Unsigned 8 Uint8
6 Unsigned 16 Uint16
7 Unsigned 32 Uint32
9 Visible String VisStr
33 Normalized value 2 bytes N2
35 Bit sequence of 16 boolean variables V2
54 Time difference w/o date TimD
Table 6.16
6.16.1
Conversion
The various attributes of each parameter are displayed in
Factory Setting. Parameter values are transferred as whole
numbers only. Conversion factors are therefore used to
transfer decimals.
4-12 Motor Speed Low Limit [Hz] has a conversion factor of
0.1. To preset the minimum frequency to 10 Hz, transfer
the value 100. A conversion factor of 0.1 means that the
value transferred is multiplied by 0.1. The value 100 is
therefore read as 10.0.
Examples:
0s ⇒ conversion index 0
0.00s ⇒ conversion index -2
0ms ⇒ conversion index -3
0.00ms ⇒ conversion index -5
Conversion index
Conversion factor
100
75
74
67
6 1000000
5 100000
4 10000
3 1000
2 100
1 10
0 1
-1 0.1
-2 0.01
-3 0.001
-4 0.0001
-5 0.00001
-6 0.000001
-7 0.0000001
Table 6.17 Conversion Table
Parameter Descriptions
Operating Instructions VLT
®
CDS302 and CDS303
122 MG34M302 - VLT
®
