3.2.2 Mechanical Mounting
1. Drill holes in accordance with the measurements
given.
2. Provide screws suitable for the surface on which
the CDS302 is to be mounted.
3. Retighten all four screws.
The frequency converter IP20 allows side-by-side instal-
lation. Because of the need for cooling, there must be a
minimum of 100 mm free air passage above and below
the frequency converter.
The back wall must always be solid. All frequency
converters are equipped with a back metal plate to
guarantee proper heat exchanger ventilation. Never
remove this metal sheet.
3.2.3 Mechanical Dimensions
IP 20 Chassis T2 (240 V) T4 (480 V) T6 (575 V)
VSH088 (15 kW) B4 B3 B3
VSH117 (18 kW) C3 B4 B4
VSH170 (22 kW) C3 B4 B4
IP 55 NEMA 12
VSH088 (15 kW) C1 B1 B1
VSH117 (18 kW) C1 B2 B2
VSH170 (22 kW) C1 B2 B2
Table 3.2 Related VSH Numbers
How to Install
Operating Instructions VLT
®
CDS302 and CDS303
MG34M302 - VLT
®
is a registered Danfoss trademark/Commercial Compressor 15
