8 General Specifications
Mains Supply 3x200 - 240 V AC
FC 301/FC 302 P15K P18K P22K
High/ Normal Load
1)
HO NO HO NO HO NO
Typical Shaft Output [kW] 15 18.5 18.5 22 22 30
Enclosure IP20 B4 C3 C3
Enclosure IP21 C1 C1 C1
Enclosure IP55, IP66 C1 C1 C1
Output current
Continuous
(3 x 200-240 V) [A]
59.4 74.8 74.8 88 88 115
Intermittent
(60 s overload)
(3 x 200-240 V) [A]
89.1 82.3 112 96.8 132 127
Continuous
kVA (208 V AC) [kVA]
21.4 26.9 26.9 31.7 31.7 41.4
Max. input current
Continuous
(3 x 200-240 V) [A]
54 68 68 80 80 104
Intermittent
(60 s overload)
(3 x 200-240 V) [A]
81 74.8 102 88 120 114
Additional specifications
IP20 max. cable cross-section
5)
(mains,
brake, motor and load sharing)
35 (2) 50 (1) 50 (1)
IP21, IP55, IP66 max. cable cross-section
5)
(mains, motor) [mm
2
(AWG)]
2)
50 (1) 50 (1) 50 (1)
IP21, IP55, IP66 max. cable cross-section
5)
(brake, load sharing) [mm
2
(AWG)]
2)
50 (1) 50 (1) 50 (1)
Max cable size with mains disconnect [mm
2
(AWG)]
2)
50, 35, 35 (1, 2, 2)
Estimated power loss
at rated max. load [W]
4)
624 737 740 845 874 1140
Weight,
enclosure IP21, IP55/IP66 [kg]
45 45 45
Efficiency
4)
0.96 0.97 0.97
Table 8.1
For fuse ratings, see 3.4.1 Fuses
1) High overload = 160% torque during 60 s, Normal overload = 110% torque during 60 s.
2) American Wire Gauge.
3) Measured using 5 m screened motor cables at rated load and rated frequency.
4) The typical power loss is at nominal load conditions and expected to be within ±15% (tolerence relates to variety in voltage and
cable conditions).
Values are based on a typical motor efficiency (eff2/eff3 border line). Motors with lower efficiency will also add to the power loss in the
and opposite.
If the switching frequency is increased compared to the default setting, the power losses may rise significantly.
and typical control card power consumptions are included. Further options and customer load may add up to 30W to the losses.
(Though typical only 4 W extra for a fully loaded control card, or options for slot A or slot B, each).
General Specifications
Operating Instructions VLT
®
CDS302 and CDS303
MG34M302 - VLT
®
is a registered Danfoss trademark/Commercial Compressor 153
8 8
