Mains Supply 3x380 - 500 V AC (FC 302), 3 x 380 - 480V AC (FC 301)
FC 301/FC 302 P15K P18K P22K
High/ Normal Load
1)
HO NO HO NO HO NO
Typical Shaft output [kW] 15 18.5 18.5 22.0 22.0 30.0
Enclosure IP20 B3 B4 B4
Enclosure IP21 B1 B2 B2
Enclosure IP55, IP66 B1 B2 B2
Output current
Continuous
(3 x 380-440 V) [A]
32 37.5 37.5 44 44 61
Intermittent (60 s overload)
(3 x 380-440 V) [A]
51.2 41.3 60 48.4 70.4 67.1
Continuous
(3 x 441-500 V) [A]
27 34 34 40 40 52
Intermittent (60 s overload)
(3 x 441-500 V) [A]
43.2 37.4 54.4 44 64 57.2
Continuous kVA
(400 V AC) [kVA]
22.2 26 26 30.5 30.5 42.3
Continuous kVA
(460 V AC) [kVA]
27.1 31.9 41.4
Max. input current
Continuous
(3 x 380-440 V) [A]
29 34 34 40 40 55
Intermittent (60 s overload)
(3 x 380-440 V ) [A]
46.4 37.4 54.4 44 64 60.5
Continuous
(3 x 441-500 V) [A]
25 31 31 36 36 47
Intermittent (60 s overload)
(3 x 441-500 V) [A]
40 34.1 49.6 39.6 57.6 51.7
Additional specifications
IP21, IP55, IP66 max. cable cross-
section
5)
(mains, brake, load sharing)
[mm
2
(AWG)]
2)
16, 10, 16 (6, 8, 6) 35,-,-(2,-,-) 35,-,-(2,-,-)
IP21, IP55, IP66 max. cable cross-
section
5)
(motor) [mm
2
(AWG)]
2)
10, 10,- (8, 8,-) 35, 25, 25 (2, 4, 4) 35, 25, 25 (2, 4, 4)
IP20 max. cable cross-section
5)
(mains,
brake, motor and load sharing)
10, 10,- (8, 8,-) 35,-,-(2,-,-) 35,-,-(2,-,-)
Max. cable cross-section with
Disconnect [mm
2
(AWG)]
2)
Estimated power loss
at rated max. load [W]
4)
379 465 444 525 547 739
Weight, enclosure IP20 [kg] 12 23.5 23.5
Weight,
enclosure IP21, IP55, IP66 [kg]
23 27 27
Efficiency
4)
0.98 0.98 0.98
Table 8.2
For fuse ratings, see 3.4.1 Fuses
1) High overload = 160% torque during 60 s., Normal overload = 110% torque during 60 s.
2) American Wire Gauge.
3) Measured using 5 m screened motor cables at rated load and rated frequency.
General Specifications
Operating Instructions VLT
®
CDS302 and CDS303
MG34M302 - VLT
®
is a registered Danfoss trademark/Commercial Compressor 155
8 8
