0-13 Readout: Linked Set-ups
Array [5]
Range: Function:
0 * [0 - 255 ] View a list of all the set-ups linked by means of
0-12 This Set-up Linked to. The parameter has one
index for each parameter set-up. The parameter
value displayed for each index represents which
set-ups are linked to that parameter set-up.
Index LCP value
0 {0}
1 {1,2}
2 {1,2}
3 {3}
4 {4}
Table 6.3 Example: Set-up 1 and Set-up 2 are
linked
0-14 Readout: Edit Set-ups / Channel
Range: Function:
0 * [-2147483648 -
2147483647 ]
View the setting of 0-11 Edit Set-up for
each of the four different communication
channels. When the number is displayed in
hex, as it is in the LCP, each number
represents one channel.
Numbers 1-4 represent a set-up number;
‘F’ means factory setting; and ‘A’ means
active set-up. The channels are, from right
to left: LCP, FC-bus, USB, HPFB1-5.
Example: The number AAAAAA21h means
that the FC bus selected Set-up 2 in
0-11 Edit Set-up, the LCP selected Set-up 1
and all others used the active set-up.
6.2.2
0-2* LCP Display
Define the display in the Graphical Logic Control Panel.
0-20 Display Line 1.1 Small
Option: Function:
Select a variable for display
in line 1, left position.
[0] None
[1501] Running Hours
[1502] kWh Counter
[1508] Number of Starts
[1509] Number of Resets
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout
[1610] Power [kW]
0-20 Display Line 1.1 Small
Option: Function:
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor Current
[1615] Frequency [%]
[1616] Torque
[1617] * Speed [RPM]
[1618 ] Motor Thermal
[1619 ] KTY sensor temperature
[1620 ] Motor Angle
[1622 ] Torque %
[1630] DC Link Voltage
[1632 ] Brake Energy /s
[1633 ] Brake Energy /2 min
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1636] Inv. Nom. Current
[1637] Inv. Max. Current
[1638] SL Control State
[1639] Control Card Temp
[1650] External Reference
[1651 ] Pulse Reference
[1652] Feedback [Unit]
[1653 ] Digi Pot Reference
[1654] Feedback 1 [Unit]
[1655 ] Feedback 2 [Unit]
[1660] Digital Input
[1661] Terminal 53 Switch Setting
[1662] Analog Input 53
[1663] Terminal 54 Switch Setting
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666 ] Digital Output [bin]
[1667] Freq. Input #29 [Hz]
[1668] Freq. Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1680 ] Fieldbus CTW 1
[1682 ] Fieldbus REF 1
[1684] Comm. Option STW
[1685 ] FC Port CTW 1
[1686 ] FC Port REF 1
[1690 ] Alarm Word
[1691 ] Alarm Word 2
[1692 ] Warning Word
[1693 ] Warning Word 2
[1694] Ext. Status Word
[2580] Cascade Status
[2581 ] Compressor Status
