0-31 Min Value of User-defined Readout
Range: Function:
Cubic units the minimum
value will be 0.
0-32 Custom Readout Max Value
Range: Function:
100.00 Custom-
ReadoutUnit*
[ par. 0-31 -
999999.99
CustomRea-
doutUnit]
This parameter sets the max
value to be shown when
the speed of the motor has
reached the set value for
4-13 Motor Speed High Limit
[RPM] or 4-14 Motor Speed
High Limit [Hz] (depends on
setting in 0-02 Motor Speed
Unit).
6.2.3 0-4* LCP Keypad
Enable and disable individual keys on the LCP keypad.
0-40 [Hand on] Key on LCP
Option: Function:
If 0-40 [Hand on] Key on LCP is included in the
Quick Menu, then define the password in
0-65 Quick Menu Password.
[0] Disabled Prevents accidental start of the frequency
converter in Hand mode.
[1] * Enabled Prevents unauthorised start in Hand mode.
0-41 [Off] Key on LCP
Option: Function:
Options are the same as in 0-40 [Hand on] Key on LCP.
0-42 [Auto on] Key on LCP
Option: Function:
Options are the same as in 0-40 [Hand on] Key on LCP.
0-43 [Reset] Key on LCP
Option: Function:
Options are the same as in 0-40 [Hand on] Key on LCP.
6.2.4 0-5* Copy/Save
Copy parameter settings between set-ups and to/from the
LCP.
0-50 LCP Copy
Option: Function:
[0] * No copy
[1] All to LCP Copies all parameters in all set-ups from
the frequency converter memory to the
LCP memory.
0-50 LCP Copy
Option: Function:
[2] All from LCP Copies all parameters in all set-ups from
the LCP memory to the frequency
converter memory.
[3] Size indep. from
LCP
Copies only the parameters that are
independent of the motor size.
0-51 Set-up Copy
Option: Function:
[0] No copy
[1] Copy to set-up 1 Copies all parameters in the present edit
set-up (defined in par. 0-11 Edit Set-up) to
Set-up 1. Likewise, select the option
corresponding to the other set-up(s).
[2] Copy to set-up 2
[3] Copy to set-up 3
[4] Copy to set-up 4
[9] Copy to all Copies the parameters in the present set-
up over to each of the set-ups 1 to 4.
6.2.5 0-6* Password
Define password access to menus.
0-60 Main Menu Password
Option: Function:
Define the password for access to the Main Menu via
the [Main Menu] key. If 0-61 Access to Main Menu w/o
Password is set to [0] Full access, this parameter will be
ignored.
0-61 Access to Main Menu w/o Password
Option: Function:
[0] * Full access
Disables the password defined in 0-60 Main
Menu Password.
[1] Read only Prevents unauthorised editing of Main Menu
parameters.
[2] No access Prevents unauthorised viewing and editing of
Main Menu parameters.
NOTE
If [0] Full access is selected, 0-60 Main Menu Password,
0-65 Quick Menu Password and 0-66 Access to Quick Menu
w/o Password are ignored.
0-65 Quick Menu Password
Option: Function:
Define the password for access to the Quick Menu via
the [Quick Menu] key. If 0-66 Access to Quick Menu w/o
Password is set to [0] Full access, this parameter will be
ignored.
Parameter Descriptions
Operating Instructions VLT
®
CDS302 and CDS303
50 MG34M302 - VLT
®
is a registered Danfoss trademark/Commercial Compressor
6
6
