13-44 Logic Rule Boolean 3
Array [6]
Option: Function:
or [21] Advanced ETR. If the alarm
164 ATEX ETR cur.lim.alarm is
active, the output will be 1.
[91] ATEX ETR cur. alarm
Selectable if 1-90 Motor Thermal
Protection is set to [20] ATEX ETR
or [21] Advanced ETR. If the alarm
166 ATEX ETR freq.lim.alarm is
active, the output will be 1.
[92] ATEX ETR freq. warning
Selectable if 1-90 Motor Thermal
Protection is set to [20] ATEX ETR
or [21] Advanced ETR. If the alarm
163 ATEX ETR cur.lim.warning is
active, the output will be 1.
[93] ATEX ETR freq. alarm
Selectable if 1-90 Motor Thermal
Protection is set to [20] ATEX ETR
or [21] Advanced ETR]. If the
warning 165 ATEX ETR
freq.lim.warning is active, the
output will be 1.
[94] RS Flipflop 0
[95] RS Flipflop 1
[96] RS Flipflop 2
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
[100] RS Flipflop 6
[101] RS Flipflop 7
6.10.7 13-5* States
13-51 SL Controller Event
Array [20]
Option: Function:
[0] * False Select the boolean input (TRUE or
FALSE) to define the Smart Logic
Controller event. See 13-01 Start
Event ([0] - [61]) and 13-02 Stop
Event ([70] - [74]) for further
description.
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
13-51 SL Controller Event
Array [20]
Option: Function:
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
Parameter Descriptions
Operating Instructions VLT
®
CDS302 and CDS303
94 MG34M302 - VLT
®
