5.3.2. Class ID 0x01
Attrib-
ute
Access Name Data
type
Min/
Max
Units Default Description
1 Get Vendor USINT 97 Danfoss Drives
Vendor Code
2 Get Device
Type
UNIT 2 AD/DC Motor
3 Get Product
Code
UNIT 100 See EDS File Sec-
tion
4 Get Revision UNIT Software version
on FC 100, 200
or 300
5 Get Status UNIT
6 Get Serial
Number
UDINT From frequency
converter
7 Get Product
Name
String FC 100, 200 or
300
10 Get/Set Heartbeat
Interval
USINT 0-255 sec 0 Off
5.3.3. Class ID 03h DeviceNet Object
This is a standard DeviceNet Object for configuration and status of the DeviceNet connection.
The attributes supported for this class are listed below.
5.3.4. Class ID 0x03
Attrib-
ute
Access Name Data
type
Min/
Max
Units Default Description
1 Get/Set MAC ID USINT 0-63 63 Node address
2 Get/Set Baud Rate USINT 0-2 0 0=125
1=250
2=500
4 Get BOC Bus-Off Counter
5 Get Allocate
informa-
tion
Only required if
predefined Mas-
ter/Slave is im-
plemented
6 Get MAC ID
Switch
changed
BOOL 0-1 0 The node ad-
dress switch has
changed since
the last power-
up/reset
7 Get Baud rate
switched
from last
power up
BOOL 0-1 0 The baud rate
switch has
changed since
the last power-
up
5. How to Access the Parameters FC 100/ 200/ 300 DeviceNet
40 MG.33.D3.02 - VLT
®
is a registered Danfoss trademark
5
