5.3.5. Class ID 04h Assembly Object
This is a standard DeviceNet Object for transfer of the I/O Instances (Process Data) described in
the section “How to control the Frequency Converter”. Using this it is possible to send or read any
of the defined Instances, either by polling or explicit messaging.
The attributes supported for this class are listed below.
5.3.6. Class ID 0x04
Attrib-
ute
Access Name Data
type
Min/
Max
Units Default Description
3 Set Data ARRAY
In-
stance
Access Size Description Parameters 10-10 selec-
tion:
20 Set 2 Words DeviceNet AC/DC Profile Instance 20/70
21 Set 2 Words DeviceNet AC/DC Profile Instance 21/71
70 Get 2 Words DeviceNet AC/DC Profile Instance 20/70
71 Get 2 Words DeviceNet AC/DC Profile Instance 21/71
100 Set 2 Words Danfoss specific, no PCD
Words
Instance 100/150
101 Set 4 Words Danfoss specific, 2 PCD Words Instance 101/151
150 Get 2 Words Danfoss specific, no PCD
Words
Instance 100/150
151 Get 4 Words Danfoss specific, 2 PCD Words Instance 101/151
5.3.7. Class ID 05h Connection Object
This is a standard DeviceNet Object for allocation and managing I/O and explicit messaging con-
nections. For this class three Instances are supported: Explicit Messages, Polled I/O and Change
of State connections.
The attributes supported for the different instances are listed below.
FC 100/ 200/ 300 DeviceNet 5. How to Access the Parameters
MG.33.D3.02 - VLT
®
is a registered Danfoss trademark 41
