Danfoss VLT FC 100 Series User Manual

[3] Jogging
[4] Max. Speed
[5] Stop and trip
[7] Select set-up 1
[8] Select set-up 2
[9] Select set-up 3
[10] Select set-up 4 Select the time-out function. The time-out function activates
when the control word fails to be updated within the time period
specified in par. 8-03
Control Word Time-out Time .
-
Off [0]: Resume control via serial bus (Fieldbus or
standard) using the most recent control word.
-
Freeze output [1]: Freeze output frequency until com-
munication resumes.
-
Stop [2]: Stop with auto restart when communication
resumes.
-
Jogging [3]: Run the motor at JOG frequency until
communication resumes.
-
Max. freq. [4]: Run the motor at maximum frequency
until communication resumes.
-
Stop and trip [5]: Stop the motor, then reset the fre-
quency converter in order to restart: via the fieldbus,
via the reset button on the LCP or via a digital input.
-
Select set-up 1-4 [7] - [10]: This option changes the
set-up upon reestablishment of communication follow-
ing a control word time-out. If communication resumes
causing the time-out situation to disappear, par. 8-05
End-of-time-out Function defines whether to resume
the set-up used before the time-out or to retain the
set-up endorsed by the time-out function. Note the
following configuration required in order to change the
set-up after a time-out: Set Par. 0-10
Active set-up to
Multi set-up
[9], and select the relevant link in par.
0-12
This Set-up Linked To .
8-05 End-of-Timeout Function
Option: Function:
Select the action after receiving a valid control word following a
time-out. This parameter is active only when par. 8-04 is set to
[Set-up 1-4].
[0] Hold set-up Retains the set-up selected in par. 8-04 and displays a warning,
until par. 8-06 toggles. Then the frequency converter resumes
its original set-up.
[1]
*
Resume set-up Resumes the set-up active prior to the time-out.
8-06 Reset Control Word Timeout
Option: Function:
[0]
*
Do not reset
6. Parameters FC 100/ 200/ 300 DeviceNet
54 MG.33.D3.02 - VLT
®
is a registered Danfoss trademark
6
