Danfoss vlt FC 102 User Guide

Power range N560 N630 N710 N800 N1M0
Drive modules 4 4 4 4 4
Rectier conguration 6-pulse/12-pulse
High/normal load NO NO NO NO NO
Typical shaft output at 400 V [kW] 560 630 710 800 1000
Typical shaft output at 460 V [hp] 750 900 1000 1200 1350
Protection rating IP00
Eciency 0.98
Output frequency [Hz] 0–590
Heat sink overtemperature trip [°C (°F)]
110 (230)
Power card ambient trip [°C (°F)]
80 (176)
Output current [A]
Continuous (at 380–440 V) 990 1120 1260 1460 1720
Intermittent (60 s overload) at 400 V 1089 1232 1386 1606 1892
Continuous (at 460/500 V) 890 1050 1160 1380 1530
Intermittent (60 s overload) at 460/500 V 979 1155 1276 1518 1683
Continuous (at 400 V) [kVA] 686 776 873 1012 1192
Continuous (at 460 V) [kVA] 709 837 924 1100 1219
Continuous (at 500 V) [kVA] 771 909 1005 1195 1325
Input current [A]
Continuous (at 400 V) 964 1090 1227 1422 1675
Continuous (at 460/500 V) 867 1022 1129 1344 1490
Power losses [W]
Drive modules at 400 V 8810 10199 11632 13253 16463
Drive modules at 460 V 7628 9324 10375 12391 13958
AC busbars at 400 V 665 680 695 722 762
AC busbars at 460 V 656 671 683 710 732
DC busbars during regeneration 218 232 250 276 318
Maximum cable size [mm
2
(mcm)]
Mains
1)
4x185 (350) 8x120 (250)
Motor 4x185 (350) 8x120 (250)
Brake 8x70 (2/0) 8x95 (3/0)
Regeneration terminals 6x120 (250) 8x120 (250) 8x150 (300) 10x150 (300)
Maximum external mains fuses
6-pulse conguration 600 V,
1600 A
600 V, 2000 A 600 V, 2500 A
12-pulse conguration 600 V, 700 A 600 V, 900 A 600 V,
1500 A
Table 7.2 FC 102, 380–480 V AC Mains Supply (4-module System)
1) For 12-pulse units, the cables between the star and delta terminals must be equal in number and length.
