7 Specications
7.1 Power-dependent Specications
7.1.1
VLT
®
HVAC Drive FC 102
Power range N315 N355 N400 N450 N500
Drive modules 2 2 2 2 2
Rectier conguration 12-pulse 6-pulse/12-pulse
High/normal load NO NO NO NO NO
Typical shaft output at 400 V [kW] 315 355 400 450 500
Typical shaft output at 460 V [hp] 450 500 600 600 700/650
Protection rating IP00
Eciency 0.98
Output frequency [Hz] 0–590
Heat sink overtemperature trip [°C (°F)]
110 (230)
Power card ambient trip [°C (°F)]
80 (176)
Output current [A]
Continuous (at 380–440 V) 588 658 745 800 880
Intermittent (60 s overload) at 400 V 647 724 820 880 968
Continuous (at 460/500 V) 535 590 678 730 780
Intermittent (60 s overload) at 460/500 V 588 649 746 803 858
Continuous (at 400 V) [kVA] 407 456 516 554 610
Continuous (at 460 V) [kVA] 426 470 540 582 621
Continuous (at 500 V) [kVA] 463 511 587 632 675
Input current [A]
Continuous (at 400 V) 567 647 733 787 875
Continuous (at 460/500 V) 516 580 667 718 759
Power losses [W]
Drive modules at 400 V 5825 6110 7069 7538 8468
Drive modules at 460 V 4998 5964 6175 6609 7140
AC busbars at 400 V 550 555 561 565 575
AC busbars at 460 V 548 551 556 560 563
DC busbars during regeneration 93 95 98 101 105
Maximum cable size [mm
2
(mcm)]
Mains
1)
4x120 (250) 4x150 (300)
Motor 4x120 (250) 4x150 (300)
Brake 4x70 (2/0) 4x95 (3/0)
Regeneration terminals 4x120 (250) 4x150 (300) 6x120 (250)
Maximum external mains fuses
6-pulse conguration – – – – 600 V, 1600 A
12-pulse conguration 700 A, 600 V –
Table 7.1 FC 102, 380–480 V AC Mains Supply (2-module System)
1) For 12-pulse units, the cables between the star and delta terminals must be equal in number and length.
Specications
VLT
®
Parallel Drive Modules
54 Danfoss A/S © 08/2017 All rights reserved. MG37L202
