Danfoss vlt FC 102 User Guide

Power range N315 N400 N450
Drive modules 2 2 2
Rectier conguration 12-pulse
High/normal load HO NO HO NO HO NO
Typical shaft output at 525–550 V [kW] 200 250 250 315 315 355
Typical shaft output at 575 V [hp] 300 350 350 400 400 450
Typical shaft output at 690 V [kW] 250 315 315 400 355 450
Protection rating IP00
Eciency 0.98
Output frequency [Hz] 0–590
Heat sink overtemperature trip [°C (°F)]
110 (230)
Power card ambient trip [°C (°F)]
80 (176)
Output current [A]
Continuous (at 550 V) 303 360 360 418 395 470
Intermittent (60 s overload) at 550 V 455 396 560 460 593 517
Continuous (at 575/690 V) 290 344 344 400 380 450
Intermittent (60 s overload) at 575/690 V 435 378 516 440 570 495
Continuous (at 550 V) 289 343 343 398 376 448
Continuous (at 575 V) 289 343 343 398 378 448
Continuous (at 690 V) 347 411 411 478 454 538
Input current [A]
Continuous (at 550 V) 299 355 355 408 381 453
Continuous (at 575 V) 286 339 339 490 366 434
Continuous (at 690 V) 296 352 352 400 366 434
Power losses [W]
Drive modules at 575 V 3688 4401 4081 4789 4502 5457
Drive modules at 690 V 3669 4352 4020 4709 4447 5354
AC busbars at 575 V 538 540 540 541 540 544
DC busbars during regeneration 88 88 89 89 90 90
Maximum cable size [mm
2
(mcm)]
Mains
1)
2x120 (250)
4x120 (250)
Motor 2x120 (250) 4x120 (250)
Brake 4x70 (2/0)
Regeneration terminals 4x120 (250)
Maximum external mains fuses 700 V, 550 A
Table 7.7 FC 202, 525–690 V AC Mains Supply (2-module System)
1) For 12-pulse units, the cables between the star and delta terminals must be equal in number and length.
Specications
VLT
®
Parallel Drive Modules
