Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
3-8* Other Ramps
3-80 Jog Ramp Time App.Dependent All set-ups TRUE -2 Uint32
3-81 Quick Stop Ramp Time App.Dependent 2 set-ups TRUE -2 Uint32
3-82 Quick Stop Ramp Type [0] Linear All set-ups TRUE - Uint8
3-83 Quick Stop S-ramp Ratio at Decel. Start 50% All set-ups TRUE 0 Uint8
3-84 Quick Stop S-ramp Ratio at Decel. End 50% All set-ups TRUE 0 Uint8
3-9* Digital Pot.Meter
3-90 Step Size 0.10% All set-ups TRUE -2 Uint16
3-91 Ramp Time 1.00 s All set-ups TRUE -2 Uint32
3-92 Power Restore [0] Off All set-ups TRUE - Uint8
3-93 Maximum Limit 100% All set-ups TRUE 0 Int16
3-94 Minimum Limit -100% All set-ups TRUE 0 Int16
3-95 Ramp Delay App.Dependent All set-ups TRUE -3 TimD
Programming
VLT
®
Decentral Drive FCD 302 Operating Instructions
46 MG04F302 - VLT
®
