5.3.5 4-** Limits / Warnings
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
4-1* Motor Limits
4-10 Motor Speed Direction null All set-ups FALSE - Uint8
4-11 Motor Speed Low Limit [RPM] App.Dependent All set-ups TRUE 67 Uint16
4-12 Motor Speed Low Limit [Hz] App.Dependent All set-ups TRUE -1 Uint16
4-13 Motor Speed High Limit [RPM] App.Dependent All set-ups TRUE 67 Uint16
4-14 Motor Speed High Limit [Hz] App.Dependent All set-ups TRUE -1 Uint16
4-16 Torque Limit Motor Mode App.Dependent All set-ups TRUE -1 Uint16
4-17 Torque Limit Generator Mode 100.0% All set-ups TRUE -1 Uint16
4-18 Current Limit App.Dependent All set-ups TRUE -1 Uint32
4-19 Max Output Frequency 132.0 Hz All set-ups FALSE -1 Uint16
4-2* Limit Factors
4-20 Torque Limit Factor Source [0] No function All set-ups TRUE - Uint8
4-21 Speed Limit Factor Source [0] No function All set-ups TRUE - Uint8
4-3* Motor Speed Mon.
4-30 Motor Feedback Loss Function [2] Trip All set-ups TRUE - Uint8
4-31 Motor Feedback Speed Error 300 RPM All set-ups TRUE 67 Uint16
4-32 Motor Feedback Loss Timeout 0.05 s All set-ups TRUE -2 Uint16
4-34 Tracking Error Function null All set-ups TRUE - Uint8
4-35 Tracking Error 10 RPM All set-ups TRUE 67 Uint16
4-36 Tracking Error Timeout 1.00 s All set-ups TRUE -2 Uint16
4-37 Tracking Error Ramping 100 RPM All set-ups TRUE 67 Uint16
4-38 Tracking Error Ramping Timeout 1.00 s All set-ups TRUE -2 Uint16
4-39 Tracking Error After Ramping Timeout 5.00 s All set-ups TRUE -2 Uint16
4-5* Adj. Warnings
4-50 Warning Current Low 0.00 A All set-ups TRUE -2 Uint32
4-51 Warning Current High ImaxVLT (P1637) All set-ups TRUE -2 Uint32
4-52 Warning Speed Low 0 RPM All set-ups TRUE 67 Uint16
4-53 Warning Speed High outputSpeedHighLimit (P413) All set-ups TRUE 67 Uint16
4-54 Warning Reference Low -999999.999 N/A All set-ups TRUE -3 Int32
4-55 Warning Reference High 999999.999 N/A All set-ups TRUE -3 Int32
4-56 Warning Feedback Low
-999999.999 ReferenceFeed-
backUnit All set-ups TRUE -3 Int32
4-57 Warning Feedback High
999999.999 ReferenceFeed-
backUnit All set-ups TRUE -3 Int32
4-58 Missing Motor Phase Function null All set-ups TRUE - Uint8
4-6* Speed Bypass
4-60 Bypass Speed From [RPM] App.Dependent All set-ups TRUE 67 Uint16
4-61 Bypass Speed From [Hz] App.Dependent All set-ups TRUE -1 Uint16
4-62 Bypass Speed To [RPM] App.Dependent All set-ups TRUE 67 Uint16
4-63 Bypass Speed To [Hz] App.Dependent All set-ups TRUE -1 Uint16
Programming
VLT
®
Decentral Drive FCD 302 Operating Instructions
MG04F302 - VLT
®
is a registered Danfoss trademark
47
5 5
