Danfoss VLT HVAC Basic Drive FC 101 Programming Guide

1.7 Electrical Overview
L1
L2
L3
3-phase
power
input
PE
PE
+10 V DC
0-10 V DC-
0-10 V DC-
50 (+10 V OUT)
54 (A IN)
53 (A IN)
55 (COM A IN/OUT)
0/4-20 mA
0/4-20 mA
42 0/4-20 mA A OUT / D OUT
45 0/4-20 mA A OUT / D OUT
18 (D IN)
19 (D IN)
27 (D IN/OUT)
29 (D IN/OUT)
12 (+24 V OUT)
24 V (NPN)
20 (COM D IN)
O V (PNP)
24 V (NPN)
O V (PNP)
24 V (NPN)
O V (PNP)
24 V (NPN)
O V (PNP)
Bus ter.
Bus ter.
RS485
Interface
RS485
(N RS485) 69
(P RS485) 68
(Com RS485 ) 61
(PNP)-Source
(NPN)-Sink
ON=Terminated
OFF=Unterminated
ON
1 2
240 V AC 3 A
Not present on all power sizes
Do not connect shield to 61
01
02
03
relay 1
relay 2
UDC+
UDC-
Motor
U
V
W
130BD467.12
06
05
04
240 V AC 3 A
Illustration 1.2 Basic Wiring Schematic Drawing
NOTICE
There is no access to UDC- and UDC+ on the following units:
•
IP20, 380–480 V, 30–90 kW (40–125 hp)
•
IP20, 200–240 V, 15–45 kW (20–60 hp)
•
IP20, 525–600 V, 2.2–90 kW (3.0–125 hp)
•
IP54, 380–480 V, 22–90 kW (30–125 hp)
Introduction
VLT
®
HVAC Basic Drive FC 101
8 Danfoss A/S © 04/2018 All rights reserved. MG18B502
