Danfoss VLT HVAC Basic Drive FC 101 Programming Guide

15-42 Voltage
Range: Function:
0* [0 - 20 ] View the FC type code. The readout is identical to
the frequency converter series power eld of the
type code denition, characters 11–12.
15-43 Software Version
Range: Function:
0* [0 - 0 ] View the software version of the frequency
converter.
15-44 Ordered TypeCode
Range: Function:
0* [0 - 40 ] View the type code string used for reordering the
frequency converter in its original conguration.
15-45 Actual Typecode String
Range: Function:
0 [0 - 40 ] View the actual type code string.
15-46 Drive Ordering No
Range: Function:
0* [0 - 8 ] View the 8-digit ordering number for reordering
the frequency converter in its original congu-
ration.
15-48 LCP Id No
Range: Function:
0* [0 - 0 ] View the LCP ID number.
15-49 SW ID Control Card
Range: Function:
0* [0 - 0 ] View the control card software version number.
15-50 SW ID Power Card
Range: Function:
0* [0 - 0 ] View the power card software version number.
15-51 Drive Serial Number
Range: Function:
0* [0 - 10 ] View the frequency converter serial number.
15-53 Power Card Serial Number
Range: Function:
0* [0 - 0 ] View the power card serial number.
15-59 Filename
Range: Function:
0 [0 - 16 ] View the current CSIV le name.
3.12 Main Menu - Data Readouts - Group 16
3.12.1 16-0* General Status
16-00 Control Word
Range: Function:
0* [0 - 65535 ] View the control word sent from the frequency
converter via the serial communication port in
hex code.
Bit Bit = 0 Bit = 1
00 Preset reference option lsb –
01
Preset reference option 2
nd
bit of
preset references
–
02 DC brake Ramp
03 Coasting Enable
04 Quick stop Ramp
05 Freeze output Ramp
06 Ramp stop Start
07 No function Reset
08 No function Jog
09 Ramp 1 Ramp 2
10 Data not valid Valid
11 Relay_A not active Relay_A activated
12 Relay_B not active Relay_B activated
13 Choice of set-up lsb –
14 No function No function
15 No function Reversing
Table 3.6 Control Word
16-01 Reference [Unit]
Range: Function:
0 ReferenceFeed-
backUnit*
[-4999 - 4999
ReferenceFeed-
backUnit]
View the present reference
value applied on impulse
or analog basis in the unit
resulting from the congu-
ration selected in
parameter 1-00 Congu-
ration Mode (Hz).
16-02 Reference [%]
Range: Function:
0 %* [-200 - 200 %] View the total reference. The total
reference is the sum of digital, analog,
preset, bus, and freeze references.
16-03 Status Word
Range: Function:
0* [0 - 65535 ] View the status word sent from the frequency
converter via the serial communication port in
hex code.
Parameters
VLT
®
HVAC Basic Drive FC 101
80 Danfoss A/S © 04/2018 All rights reserved. MG18B502
