Danfoss VLT HVAC Basic Drive FC 101 Programming Guide

5.1.6 4-** Limits/Warnings
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
4-1* Motor Limits
4-10 Motor Speed Direction [2] Both directions All set-ups FALSE – Uint8
4-12 Motor Speed Low Limit [Hz] 0 Hz All set-ups FALSE -1 Uint16
4-14 Motor Speed High Limit [Hz] ExpressionLimit All set-ups FALSE -1 Uint16
4-18 Current Limit ExpressionLimit All set-ups FALSE 0 Uint16
4-19 Max Output Frequency ExpressionLimit All set-ups FALSE -1 Uint16
4-4* Adj. Warnings 2
4-40 Warning Freq. Low ExpressionLimit All set-ups FALSE -1 Uint16
4-41 Warning Freq. High ExpressionLimit All set-ups FALSE -1 Uint16
4-5* Adj. Warnings
4-50 Warning Current Low 0 A All set-ups FALSE -2 Uint32
4-51 Warning Current High ExpressionLimit All set-ups FALSE -2 Uint32
4-54 Warning Reference Low -4999 N/A All set-ups FALSE -3 Int32
4-55 Warning Reference High 4999 N/A All set-ups FALSE -3 Int32
4-56 Warning Feedback Low -4999 ProcessCtrlUnit All set-ups FALSE -3 Int32
4-57 Warning Feedback High 4999 ProcessCtrlUnit All set-ups FALSE -3 Int32
4-58 Missing Motor Phase Function [1] On All set-ups FALSE – Uint8
4-6* Speed Bypass
4-61 Bypass Speed From [Hz] 0 Hz All set-ups FALSE -1 Uint16
4-63 Bypass Speed To [Hz] 0 Hz All set-ups FALSE -1 Uint16
4-64 Semi-Auto Bypass Set-up [0] O All set-ups FALSE – Uint8
5.1.7 5-** Digital In/Out
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
5-0* Digital I/O mode
5-00 Digital Input Mode [0] PNP 1 set-up FALSE – Uint8
5-03 Digital Input 29 Mode [0] PNP All set-ups FALSE – Uint8
5-1* Digital Inputs
5-10 Terminal 18 Digital Input [8] Start All set-ups FALSE – Uint8
5-11 Terminal 19 Digital Input [0] No operation All set-ups FALSE – Uint8
5-12 Terminal 27 Digital Input ExpressionLimit All set-ups FALSE – Uint8
5-13 Terminal 29 Digital Input [14] Jog All set-ups FALSE – Uint8
5-3* Digital Outputs
5-34 On Delay, Digital Output 0.01 s All set-ups FALSE -2 Uint16
5-35 O Delay, Digital Output 0.01 s All set-ups FALSE -2 Uint16
5-4* Relays
5-40 Function Relay ExpressionLimit All set-ups FALSE – Uint8
5-41 On Delay, Relay 0.01 s All set-ups FALSE -2 Uint16
5-42 O Delay, Relay 0.01 s All set-ups FALSE -2 Uint16
5-5* Pulse Input
5-50 Term. 29 Low Frequency 20 Hz All set-ups FALSE 0 Uint32
5-51 Term. 29 High Frequency 32000 Hz All set-ups FALSE 0 Uint32
5-52 Term. 29 Low Ref./Feedb. Value 0 N/A All set-ups FALSE -3 Int32
5-53 Term. 29 High Ref./Feedb. Value ExpressionLimit All set-ups FALSE -3 Int32
5-9* Bus Controlled
5-90 Digital & Relay Bus Control 0 N/A All set-ups FALSE 0 Uint32
Parameter Lists Programming Guide
MG18B502 Danfoss A/S © 04/2018 All rights reserved. 109
5 5
