Danfoss VLT HVAC Basic Drive FC 101

Par.
No. #
Parameter description Default value 2-set-up Change during
operation
Conversion
index
Type
1-25 Motor Nominal Speed ExpressionLimit All set-ups FALSE 67 Uint16
1-26 Motor Cont. Rated Torque ExpressionLimit All set-ups FALSE -1 Uint32
1-29 Automatic Motor Adaption (AMA) [0] O All set-ups FALSE – Uint8
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs) ExpressionLimit All set-ups FALSE -3 Uint32
1-33 Stator Leakage Reactance (X1) ExpressionLimit All set-ups FALSE -3 Uint32
1-35 Main Reactance (Xh) ExpressionLimit All set-ups FALSE -2 Uint32
1-37 d-axis Inductance (Ld) ExpressionLimit All set-ups FALSE -6 Int32
1-38 q-axis Inductance (Lq) ExpressionLimit All set-ups FALSE -6 Int32
1-39 Motor Poles ExpressionLimit All set-ups FALSE 0 Uint8
1-4* Adv. Motor Data II
1-40 Back EMF at 1000 RPM ExpressionLimit All set-ups FALSE 0 Uint16
1-44 d-axis Inductance Sat. (LdSat) ExpressionLimit All set-ups FALSE -6 Int32
1-45 q-axis Inductance Sat. (LqSat) ExpressionLimit All set-ups FALSE -6 Int32
1-46 Position Detection Gain 100% All set-ups FALSE 0 Uint16
1-48 Current at Min Inductance for d-axis 100% All set-ups FALSE 0 Int16
1-49 Current at Min Inductance for q-axis 100% All set-ups FALSE 0 Uint16
1-5* Load Indep. Setting
1-50 Motor Magnetisation at Zero Speed 100% All set-ups FALSE 0 Uint16
1-52 Min Speed Normal Magnetising [Hz] 1 Hz All set-ups FALSE -1 Uint16
1-55 U/f Characteristic - U ExpressionLimit All set-ups FALSE -1 Uint16
1-56 U/f Characteristic - F ExpressionLimit All set-ups FALSE -1 Uint16
1-6* Load Depen. Setting
1-62 Slip Compensation ExpressionLimit All set-ups FALSE 0 Int16
1-63 Slip Compensation Time Constant 0.1 s All set-ups FALSE -2 Uint16
1-64 Resonance Dampening 100% All set-ups FALSE 0 Uint16
1-65 Resonance Dampening Time Constant 0.005 s All set-ups FALSE -3 Uint16
1-66 Min. Current at Low Speed 50% All set-ups FALSE 0 Uint32
1-7* Start Adjustments
1-70 PM Start Mode [1] Parking All set-ups FALSE – Uint8
1-71 Start Delay 0 s All set-ups FALSE -1 Uint8
1-72 Start Function [2] Coast/delay time All set-ups FALSE – Uint8
1-73 Flying Start [0] Disabled All set-ups FALSE – Uint8
1-8* Stop Adjustments
1-80 Function at Stop [0] Coast All set-ups FALSE – Uint8
1-82 Min Speed for Function at Stop [Hz] 0 Hz All set-ups FALSE -1 Uint16
1-88 AC Brake Gain 1.4 N/A All set-ups FALSE -1 Uint16
1-9* Motor Temperature
1-90 Motor Thermal Protection [4] ETR trip 1 All set-ups FALSE – Uint8
1-93 Thermistor Source [0] None All set-ups FALSE – Uint8
Parameter Lists Programming Guide
MG18B502 Danfoss A/S © 04/2018 All rights reserved. 107
5 5
