Danfoss VLT HVAC Basic Drive FC 101 Programming Guide

13-01 Start Event
Option: Function:
[26] Logic rule 0 Use the result of logic rule 0 in the logic
rule.
[27] Logic rule 1 Use the result of logic rule 1 in the logic
rule.
[28] Logic rule 2 Use the result of logic rule 2 in the logic
rule.
[29] Logic rule 3 Use the result of logic rule 3 in the logic
rule.
[33] Digital input
DI18
Use the value of DI18 in the logic rule
(High = true).
[34] Digital input
DI19
Use the value of DI19 in the logic rule
(High = true).
[35] Digital input
DI27
Use the value of DI27 in the logic rule
(High = true).
[36] Digital input
DI29
Use the value of DI29 in the logic rule
(High = true).
[39]
*
Start
command
This event is true if the frequency
converter is started (either via digital
input, eldbus, or other).
[40] Drive stopped This event is true if the frequency
converter is stopped or coasted (either via
digital input, eldbus, or other).
[42] Auto Reset
Trip
This event is true if the frequency
converter is tripped (but not trip-locked)
and an automatic reset is issued.
[50] Comparator 4 Use the result of comparator 4 in the logic
rule.
[51] Comparator 5 Use the result of comparator 5 in the logic
rule.
[60] Logic rule 4 Use the result of logic rule 4 in the logic
rule.
[61] Logic rule 5 Use the result of logic rule 5 in the logic
rule.
[83] Broken Belt A broken-belt condition is detected.
Enable this function in
parameter 22-60 Broken Belt Function.
13-02 Stop Event
Option: Function:
Select the condition (true or false) which
deactivates the smart logic controller.
[0] False Enters the xed value of false in the logic
rule.
[1] True Enters the xed value of true in the logic
rule.
[2] Running See parameter 13-01 Start Event for further
description.
13-02 Stop Event
Option: Function:
[3] In range See parameter 13-01 Start Event for further
description.
[4] On reference See parameter 13-01 Start Event for further
description.
[7] Out of current
range
See parameter 13-01 Start Event for further
description.
[8] Below I low See parameter 13-01 Start Event for further
description.
[9] Above I high See parameter 13-01 Start Event for further
description.
[16] Thermal
warning
See parameter 13-01 Start Event for further
description.
[17] Mains out of
range
See parameter 13-01 Start Event for further
description.
[18] Reversing See parameter 13-01 Start Event for further
description.
[19] Warning See parameter 13-01 Start Event for further
description.
[20] Alarm (trip) See parameter 13-01 Start Event for further
description.
[21] Alarm (trip
lock)
See parameter 13-01 Start Event for further
description.
[22] Comparator 0 Use the result of comparator 0 in the
logic rule.
[23] Comparator 1 Use the result of comparator 1 in the
logic rule.
[24] Comparator 2 Use the result of comparator 2 in the
logic rule.
[25] Comparator 3 Use the result of comparator 3 in the
logic rule.
[26] Logic rule 0 Use the result of logic rule 0 in the logic
rule.
[27] Logic rule 1 Use the result of logic rule 1 in the logic
rule.
[28] Logic rule 2 Use the result of logic rule 2 in the logic
rule.
[29] Logic rule 3 Use the result of logic rule 3 in the logic
rule.
[30] SL Time-out 0 Use the result of timer 0 in the logic rule.
[31] SL Time-out 1 Use the result of timer 1 in the logic rule.
[32] SL Time-out 2 Use the result of timer 2 in the logic rule.
[33] Digital input
DI18
Use the value of DI18 in the logic rule
(High = true).
[34] Digital input
DI19
Use the value of DI19 in the logic rule
(High = true).
Parameters
VLT
®
HVAC Basic Drive FC 101
68 Danfoss A/S © 04/2018 All rights reserved. MG18B502
33
