[23] Setup select bit 0 Set par. 0-10 Active set-up to Multi set-up.
Logic 0 = set-up 1, Logic 1 = Set-up 2.
[26] Precise stop inverse
(only terminal 33)
Prolong the stop signal to give a precise stop independent of scan time. The function is available for terminal
33 only.
[27] Start, precise stop (on-
ly terminal 33)
As [26], but including Start.
[28] Catch up Select Catch up/Slow down to increase or reduce the resulting reference value by the percentage set in par.
3-12.
[29] Slow down Same as Catch up [28]
[32] Pulse input (only termi-
nal 33)
Select Pulse input when using a pulse sequence as either reference or feedback. Scaling is done in par. group
5-5*.
[34] Ramp bit 0 Logic 0 = Ramp1, see par. 3-4*.
Logic 1 = Ramp2, see par. 3-5*.
[60] Counter A (up) Input for counter A.
[61] Counter A (down) Input for counter A.
[62] Reset counter A Input for reset of counter A.
[63] Counter B (up) Input for counter B.
[64] Counter B (down) Input for counter B.
[65] Reset counter B Input for reset of counter B.
5-10 Terminal 18 Digital Input
Option: Function:
[8] *
Start Select function from available digital input range.
See par. 5-1* for choices.
5-11 Terminal 19 Digital Input
Option: Function:
[10] *
Reversing Select function from available digital input range.
See par. 5-1* for choices.
5-12 Terminal 27 Digital Input
Option: Function:
[1] *
Reset Select function from available digital input range.
See par. 5-1* for choices.
5-13 Terminal 29 Digital Input
Option: Function:
[14] *
Jog Select function from available digital input range.
See par. 5-1* for choices.
5-15 Terminal 33 Digital Input
Option: Function:
[16] *
Preset bit 0 Select function from available digital input range.
See par. 5-1* for choices.
4.6.3. 5-4* Relays
Parameter group for configuring timing and output functions for relays.
[0] No Operation Default for all digital and relay outputs.
[1] Control Ready Control board receives supply voltage.
[2] Drive Ready Frequency converter is ready for operation and applies supply signal on control board.
[3] Drive Ready, Remote Frequency converter is ready for operation in Auto On-mode.
4. Parameter Descriptions VLT
p
Micro Drive FC 51
34 MG.02.C4.02 - VLT
p
is a registered Danfoss trademark
